Consumer units
MISTRAL41F – Order codes with terminals | Flush-mounted – Brick wall

MISTRAL41F – Order codes 650
Description N° of Dimensions
modules W x H x D Type
[18 mm] GWT [mm] Order code number Packaging
MISTRAL41 flush
4 modules Opaque door 8M 12SM 8 650 232 x 250 x 108 1SLM004102A1102 41A08X11A 1/12
Transparent door 8M 12SM 8 650 232 x 250 x 108 1SLM004101A1202 41A08X12A 1/12

1 2 3 4 5 6 7 8 9 10 11 1 2 3 1 2 3
1SPE007715F0751 1SPE007715F0731 1SPE007715F0741
12 modules
Opaque door 12M 12SM 12 650 320 x 250 x 108 1SLM004102A1103 41A12X11A 1/9
Transparent door 12M 12SM 12 650 320 x 250 x 108 1SLM004101A1203 41A12X12A 1/9

18 modules 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 1 2 3
1SPE007715F0752
1SPE007715F0731 1SPE007715F0741
Opaque door 18M 22SM 18 650 430 x 250 x 108 1SLM004102A1104 41A18X11A 1/16
Transparent door 18M 22SM 18 650 430 x 250 x 108 1SLM004101A1204 41A18X12A 1/16

24 modules 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 1 2 3 4 5 1 2 3 4 5
1SPE007715F0753 1SPE007715F0732 1SPE007715F0742

Opaque door 24M 32SM 24 650 320 x 435 x 108 1SLM004102A1105 41A12X21A 1/5
Transparent door 24M 32SM 24 650 320 x 435 x 108 1SLM004101A1205 41A12X22A 1/5

36 modules 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 1 2 3 4 5 6 7
1SPE007715F0752 1SPE007715F0733 1SPE007715F0743
Opaque door 36M 2F 42SM 36 650 430 x 435 x 108 1SLM004102A1106 41A18X21A 1/3
Transparent door 36M 2F 42SM 36 650 430 x 435 x 108 1SLM004101A1206 41A18X22A 1/3

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
1SPE007715F0753

36 modules
1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9
1SPE007715F0734 1SPE007715F0744
Opaque door 36M 3F 44SM 36 650 320 x 600 x 108 1SLM004102A1107 41A12X31A 1/4
Transparent door 36M 3F 44SM 36 650 320 x 600 x 108 1SLM004101A1207 41A12X32A 1/4

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 1 2 3 4 5
1SPE007715F0752 1SPE007715F0732 1SPE007715F0742
19

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 1 2 3 4 5
1SPE007715F0752 1SPE007715F0732 1SPE007715F0742
