Consumer units
MISTRAL41F – Order codes | Flush-mounted – Brick wall

MISTRAL41F – Order codes 650
Description N° of Dimensions
modules W x H x D Type
[18 mm] GWT [mm] Order code number Packaging
Consumer units MISTRAL41 flush 650 - 1 Row
4 modules Opaque door 4M 4 650 152 x 202 x 105 1SLM004100A1100 41A04X11 1/24
Transparent door 4M 4 650 152 x 202 x 105 1SLM004100A1200 41A04X12 1/24
Front transparent door 4M 4 650 152 x 202 x 25 1SLM004100A1600 41F04X12 1/24
Flush-mounting box 4M 4 650 129 x 182 x 80 1SLM004100A1700 41S04X1 1/24

Opaque door 6M 6 650 192 x 202 x 105 1SLM004100A1101 41A06X11 1/18
6 modules
Transparent door 6M 6 650 192 x 202 x 105 1SLM004100A1201 41A06X12 1/18
Front transparent door 6M 6 650 192 x 202 x 25 1SLM004100A1601 41F06X12 1/18
Flush-mounting box 6M 6 650 149 x 182 x 80 1SLM004100A1701 41S06X1 1/18

Opaque door 8M 8 650 232 x 250 x 108 1SLM004100A1102 41A08X11 1/12
Transparent door 8M 8 650 232 x 250 x 108 1SLM004100A1202 41A08X12 1/12
8 modules
Front opaque door 8M 8 650 232 x 250 x 28 1SLM004100A1502 41F08x11 1/12
Front transparent door 8M 8 650 232 x 250 x 28 1SLM004100A1602 41F08X12 1/12
Flush-mounting box 8M 8 650 206 x 230 x 80 1SLM004100A1702 41S08X1 1/12

Opaque door 12M 12 650 320 x 250 x 108 1SLM004100A1103 41A12X11 1/9
Transparent door 12M 12 650 320 x 250 x 108 1SLM004100A1203 41A12X12 1/9
12 modules Front opaque door 12M 12 650 320 x 250 x 28 1SLM004100A1503 41F12x11 1/9
Front transparent door 12M 12 650 320 x 250 x 28 1SLM004100A1603 41F12X12 1/9
Flush-mounting box 12M 12 650 294 x 230 x 80 1SLM004100A1703 41S12X1 1/9

Opaque door 18M 18 650 430 x 250 x 108 1SLM004100A1104 41A18X11 1/6
Transparent door 18M 18 650 430 x 250 x 108 1SLM004100A1204 41A18X12 1/6
18 modules Front transparent door 18M 18 650 430 x 250 x 28 1SLM004100A1604 41F18X12 1/6
Flush-mounting box 18M 18 650 404 x 230 x 80 1SLM004100A1704 41S18X1 1/6

Consumer units MISTRAL41 flush 650 - 2 Rows
Opaque door 24M 24 650 320 x 435 x 108 1SLM004100A1105 41A12X21 1/5
Transparent door 24M 24 650 320 x 435 x 108 1SLM004100A1205 41A12X22 1/5
Front opaque door 24M 24 650 320 x 435 x 28 1SLM004100A1505 41F12x21 1/5
24 modules
Front transparent door 24M 24 650 320 x 435 x 28 1SLM004100A1605 41F12X22 1/5
Flush-mounting box 24M 24 650 294 x 415 x 80 1SLM004100A1705 41S12X2 1/5

Opaque door 36M 2F 36 650 430 x 435 x 108 1SLM004100A1106 41A18X21 1/3
Transparent door 36M 2F 36 650 430 x 435 x 108 1SLM004100A1206 41A18X22 1/3

36 modules
