Consumer units
MISTRAL41F – Order codes | Flush-mounted – Hollow wall

MISTRAL41F – Order codes 850
Description N° of Dimensions
modules W x H x D Type
[18 mm] GWT [mm] Order code number Packaging
Consumer units MISTRAL41 flush 850 - 1 Row
4 modules
Opaque door 4M 4 850 152 x 202 x 105 1SLM004100A1300 41C04X11 1/24
Transparent door 4M 4 850 152 x 202 x 105 1SLM004100A1400 41C04X12 1/24

Opaque door 6M 6 850 192 x 202 x 105 1SLM004100A1301 41C06X11 1/18
Transparent door 6M 6 850 192 x 202 x 105 1SLM004100A1401 41C06X12 1/18
6 modules
Opaque door 8M 8 850 232 x 250 x 108 1SLM004100A1302 41C08X11 1/12
Transparent door 8M 8 850 232 x 250 x 108 1SLM004100A1402 41C08X12 1/12

Opaque door 12M 12 850 320 x 250 x 108 1SLM004100A1303 41C12X11 1/9
Transparent door 12M 12 850 320 x 250 x 108 1SLM004100A1403 41C12X12 1/9
8 modules
Opaque door 18M 18 850 430 x 250 x 108 1SLM004100A1304 41C18X11 1/6
Transparent door 18M 18 850 430 x 250 x 108 1SLM004100A1404 41C18X12 1/6

Consumer units MISTRAL41 flush 850 - 2 Rows
Opaque door 24M 24 850 320 x 435 x 108 1SLM004100A1305 41C12X21 1/5
Transparent door 24M 24 850 320 x 435 x 108 1SLM004100A1405 41C12X22 1/5
12 modules
Opaque door 36M 2F 36 850 430 x 435 x 108 1SLM004100A1306 41C18X21 1/3
Transparent door 36M 2F 36 850 430 x 435 x 108 1SLM004100A1406 41C18X22 1/3

18 modules

24 modules

36 modules
