Consumer units
MISTRAL41W – Order codes with terminals (650)

MISTRAL41W – Order codes
Description N° of Dimensions
modules W x H x D
[18 mm] GWT [mm] Order code Type code Packaging
Consumer units MISTRAL41W
Opaque door 8M 12SM 8 650 202 x 257 x 120 1SLM004102A3102 41P08X11A 1/7
8 modules Transparent door 8M 12SM 8 650 202 x 257 x 120 1SPE007717F0321 41P08X12A 1/7

1 2 3 4 5 6 7 8 9 10 11 1 2 3 1 2 3
1SPE007715F0751 1SPE007715F0731 1SPE007715F0741
12 modules
Opaque door 12M 12SM 12 650 292 x 257 x 120 1SLM004102A3103 41P12X11A 1/3
Transparent door 12M 12SM 12 650 292 x 257 x 120 1SPE007717F0421 41P12X12A 1/3

18 modules 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 1 2 3
1SPE007715F0752
1SPE007715F0731 1SPE007715F0741
Opaque door 18M 22SM 18 650 382 x 257 x 120 1SLM004102A3104 41P12X21A 1/3
Transparent door 18M 22SM 18 650 382 x 257 x 120 1SPE007717F0821 41P12X22A 1/3

24 modules 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 1 2 3 4 5 1 2 3 4 5
1SPE007715F0753 1SPE007715F0732 1SPE007715F0742

Opaque door 24M 32SM 24 650 292 x 382 x 120 1SLM004102A3105 41P12X31A 1/2
Transparent door 24M 32SM 24 650 292 x 382 x 120 1SPE007717F0521 41P12X32A 1/2

36 modules
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 1 2 3 4 5 6 7
1SPE007715F0753 1SPE007715F0733 1SPE007715F0743

Opaque door 36M 2F 42SM 36 650 382 x 382 x 120 1SLM004102A3106 41P12X41A 1/2
Transparent door 36M 2F 42SM 36 650 382 x 382 x 120 1SPE007717F0921 41P12X42A 1/2

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
36 modules 1SPE007715F0753

1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9
1SPE007715F0734 1SPE007715F0744
Opaque door 36M 3F 44SM 36 650 292 x 507 x 120 1SLM004102A3107 41P18X11A 1/2
Transparent door 36M 3F 44SM 36 650 292 x 507 x 120 1SPE007717F0621 41P18X12A 1/2

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 1 2 3 4 5
1SPE007715F0752 1SPE007715F0732 1SPE007715F0742

19
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 1 2 3 4 5
1SPE007715F0752 1SPE007715F0732 1SPE007715F0742
