20/74 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Automation boards
Ordering codes - SRX enclosures

Special Drilling Service
The overprice amount depends on the number of individual drilled parts and not on the num-
ber of holes.
D For single part it means: A-door B-plate; C-housing; D-top/bottom part.
C Please note that the minimum quantity is 10 pieces with a single code. The price of the spe-
A cial drilling service depends on the number of parts to be drilled and on the amount of enclo-
C sures to be drilled.

B
No. of enclosures to be
Description Code drilled
Extra cost for drilling service per individual drilled part FORSRX ≥ 10
(A-B-C-D)

The special drilling service for standard size enclosures in quantities equal to or greater than
10 units with a single code has to be managed with code SRN ... SPEC + overprice FORSR/
FORSR1/FORSSR2 (see table) equal to the number of enclosures and the number of parts to
be drilled + hole layout to be attached to the order.
Example: SRN4320XSPEC 10
FORSRX 10

Example: Enclosure (10 pcs) with door and plate to be drilled (2 parts)
SRN4320XSPEC 10
FORSRX 20
DRAWINGS TO BE ATTACHED
Non-standard enclosure sizes, special drilling
Request feasibility of implementation by completing the relevant Form for special quotations
and send it together with the drill layout to the R&D ECS office. Management is per offer.
If the offer is accepted and after having received it, it will be possible to place the order with
the codes indicated in the offer.

Painting Special Service
Request feasibility of implementation by completing the relevant Form for special quota-
tions and send it to the R&D ECS office. Management is per offer.
If the offer is accepted and after having received it, it will be possible to place the order with
the codes indicated in the offer.
