20/72 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Automation boards
Ordering codes - SRX enclosures

DIN rail and fixing brackets

Package/
No. W No. of
Description modules (mm) Code pieces
DIN rail and fixing brackets 14 400 GD4006 1/1
DIN rail and fixing brackets 25 600 GD6006 1/1
DIN rail and fixing brackets 36 800 GD8006 1/1
Depth adapter
No.1 depth adapter for Tmax T1-T2-T3-XT1-XT3 AP6001 1/4
W = 600 mm
AP6001
Spray protection roof
Improves protection against infiltration by liquids and accidental sprays.
Made of 15/10 thick AISI 304 stainless steel.

Spray protection roof
Dimensions (mm) Package/
No. of
W D Code pieces
200 150 TT2015X 1/1
300 150 TT3015X 1/1
400 150 TT4015X 1/1
300 200 TT3020X 1/1
400 200 TT4020X 1/1
500 200 TT5020X 1/1
600 200 TT6020X 1/1
500 250 TT5025X 1/1
600 250 TT6025X 1/1
600 300 TT6030X 1/1
800 300 TT8030X 1/1

Closing systems
May substitute standard fasteners for the external doors.

AA8001X
Package/
No. of
Description Code pieces
Box Ø 19 mm double tongue made of chrome- AA8001X 1/1
finished plastic and key for external door
AA8002 Box Ø 19 mm with safety insert and Yale type AA8002 (1) 1/1
key for external door
Box Ø 19 mm with handle and Yale type key AA8003 (1) 1/1
for external door
Box Ø 19 mm with triangular insert for external AA5200 (1) 1/1
door
AA8003 Plastic key for triangular insert AA5200 AA5190 1/1
for external door
Box with double tongue insert made of plastic EV1008 1/1
with key for inner door (without tongue)
Single code Yale insert for inner door EV1036 1/1
20
EV1008
Ronis 455 insert for inner door EV1037 1/1
3mm double tongue insert for inner door EV1039 1/1
(1) Only for external door
