20/70 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Automation boards
Ordering codes - SRX enclosures

Plinth
25/10 thick AISI 304 stainless steel plinth.

Plinth
Dimensions (mm) Package/
H W D Code No. of pieces
100 400 200 ZA4020X 1/1
100 500 200 ZA5020X 1/1
100 250 ZA5025X 1/1
100 600 200 ZA6020X 1/1
100 300 ZA6030X 1/1
100 800 300 ZA8030X 1/1

Frame for DIN rail
Internal supports for fixing modular panels and DIN rails, with compensation panels, made
of AISI 304 stainless steel.

Dimensions
(mm)
Package/
Description H W Code No. of pieces
Supports for 14 DIN mod. x 2 500 400 KD5040X 1/1
rows
Supports for 14 DIN mod. x 3 600 400 KD6040X 1/1
rows
Supports for 25 DIN mod. x 4 800 600 KD8060X 1/1
rows
Supports for 36 DIN mod. x 5 1000 800 KD1080X 1/1
rows

20
