TERMINAL BOXES - STAINLESS STEEL

Features:
- Material: Stainless steel AISI316.
- Thickness: 1.5mm.

- Mounting Rails: 2mm Alu-zinc.
- Finish: Wet grinding (180).
- Construction: Terminal boxes are of fully welded type construction. The front lip of the enclosure is folded to provide rigidity.
- Cover: The cover is lift-off type with 4 captive screws. The gasket is continuous formed polyurethane which provides excellent sealing and
a high IP rating over a very long life.

- Ratings & Approvals: IP66 / UL & CSA approved.

TERMINAL BOXES - STAINLESS STEEL

Dimensions (mm) Weight Part No.
W x H x D (kg) SS316 METAL
150 x 150 x 80 1.71 TS15158-6 ENCLOSURES
300 x 150 x 80 2.63 TS30158-6
200 x 200 x 80 2.43 TS20208-6
300 x 200 x 80 3.17 TS30208-6
150 x 150 x 120 2.44 TS151512-6
300 x 150 x 120 3.52 TS301512-6
200 x 200 x 120 3.26 TS202012-6
300 x 200 x 120 4.11 TS302012-6
400 x 200 x 120 4.96 TS402012-6
TS15158-6
300 x 300 x 120 5.26 TS303012-6

INTERNAL VIEW

ACCESSORIES
Description Part No.
Stainless steel wall mounting bracket set pk4 TSWMB

TSWMB
