OUTLETS & ENCLOSED ISOLATORS

Features: IPG SWITCHED SOCKET OUTLETS
- IP53 Rating
- Tested to AS/NZS 3112. Rating Cable Size Pack
- Padlockable ON/OFF. (A) Outlets Max. Qty Part No.
- High grip buttons. 10 1 6mm 2 30 IPG101
- Entries - 6 x 25mm plain. 10 2 IPG102
- Dimensions single: 85mmW x 85mmH x 86mmD.
- Dimensions double: 115mmW x 85mmH x 86mmD.

IPG101
Features: IPX SWITCHED SOCKET OUTLETS
- IP54 Rating.
- Tested to AS/NZS 3112. Rating Outlets Cable Size Pack Part No.
Qty
Max.
(A)
- Captive cover screws.
- Entries - 5 x 25mm plain & 1 x 25mm threaded. 10 2 6mm 2 36 IPX102
15 IPX152
- Dimensions double: 115mmW x 85mmH x 83mmD.

IPX102
Features: IPM WEATHERPROOF ISOLATORS - IP66
- IP66 Rating.
- Tested to IEC 60947.3 & AS3133. Rating AS3133 Voltage Cable Size Pack
- Full size heavy duty switch mechanism. (A) Poles M-rating Rating (V) Max. Qty Part No.
- Padlockable. 20 1 120 240 IPM201
- Stainless steel fixing screws. 35 1 150 240 25mm² 30 IPM351
- Compact 136mm high. 35 3 150 415 IPM353
- 4 x M25 threaded entries.
- 1 x 25mm smooth side entry. - Dimensions: 82mmW x 136mmH x 89mmD.
- Includes earth & neutral terminals.

IPM201
Features: IPW WEATHERPROOF ISOLATORS - IP66
- IP66 Rating.
- Max cable 25mm . 2 Rating AS3133 Voltage Cable Size Pack
- Tested to AS/NZS 3947.3.2.2001. (A) Poles M-rating Rating (V) Max. Qty Part No.
- Gland entries 4 x M25. 20 1 140 240 IPW201
- Includes Earth & Neutral terminals. 20 3 120 415 IPW203
- High visibility ON/OFF indication. 20 4 100 415 IPW204
- High strength locking screws. 35 1 180 240 IPW351
- Pad-lockable handle with front and rear entries.
35 2 180 240 25mm² 20 IPW352
35 3 160 415 IPW353
63 1 200 240 IPW631
63 3 200 415 IPW633
63 4 200 415 IPW634
- Dimensions: 82.5mmW x 167mmH x 89mmD.

IPW201
