DIN RAIL INSERTS
Galvanised DIN chassis
Includes slotted escutcheon in RAL 7035 Grey.
All fixing hardware included

Part Number Dimensions A x B x C Modules No of Rows
CH4040/1520 400H X 400W 150-200D 45 3 X 15
CH4060/1520 400H X 600W 150-200D 78 3 X 26
CH4060/2530 400H X 600W 250-300D 78 3 X 26
CH6040/1520 600H X 400W 150-200D 64 4 X 16
CH6040/2530 600H X 400W 250-300D 64 4 X 16
CH6060/1520 600H X 600W 150-200D 104 4 X 26
CH6060/2530 600H X 600W 250-300D 104 4 X 26
CH8060/1520 800H X 600W 150-200D 128 4 X 26
1 X 24
CH8060/2530 800H X 600W 250-300D 128 4 X 26
1 X 24
CH1060/20 1000H X 600W 200D 156 6 X 26
CH1060/30 1000H X 600W 300D 156 6 X 26

CANOPIES
RAL 7035 Grey UV tolerant polyester powdercoat
Slopes front to back

Part Number Description
TEJ2015G* 200W X 150D
TEJ2515G 250W X 150D
TEJ3015G 300W X 150D
TEJ3020G 300W X 200D
TEJ4015G 400W X 150D
TEJ4020G* 400W X 200D
TEJ4025G 400W X 250D
TEJ4030G 400W X 300D
TEJ5020G* 500W X 200D
TEJ5025G 500W X 250D
TEJ6020G* 600W X 200D
TEJ6025G 600W X 250D
TEJ6030G* 600W X 300D
TEJ6040G 600W X 400D
TEJ8020G* 800W X 200D
TEJ8025G* 800W X 250D
TEJ8030G* 800W X 300D
TEJ1030G* 1000W X 300D
TEJ1040G 1000W X 400D
TEJ1230G* 1200W X 300D

Available in orange:
RAL 2008 Orange epoxy powder coat.
*Replace G with A

DEPTH ADJUSTING BRACKETS
For adjusting mounting plate depth
For inner door fitting.
Galvanised Steel

Part Number Description
SP150 FOR 150D PACK4
SP200 FOR 200D PACK4
SP250 FOR 250D PACK4
SP285 FOR 285D PACK4
SP300 FOR 300D PACK4
SP400 FOR 400D PACK4
