ABB MOTOR PROTECTION AND CONTROL 5/13

—

AS09 ... AS16 and
ASL09 ... ASL16 3-pole contactors
Main accessories

Front-mounted instantaneous auxiliary contact blocks
1SBC101036F0014 For contactors Auxiliary Type Order code Pkg Weight
qty
contacts
(1 pce)

kg
CA3-10
AS09 … AS16 1 0 CA3-10 1SBN011010T1010 10 0.011
ASL09 … ASL16 0 1 CA3-01 1SBN011010T1001 10 0.011
1SBC101069F0014 Mechanical interlock unit Type Order code Pkg Weight
For contactors
qty
(1 pce)
kg 05
VM3
AS09 … AS16, ASL09 … ASL16 VM3 1SBN031005T1000 10 0.002
Surge suppressors
1SBC574001F0301 For contactors Rated control circuit Type Order code Pkg Weight
(1 pce)
qty
voltage - Uc
kg
AS09 ... AS16, V 24...50 AC DC RV5/50 1SBN050010R1000 2 0.015
RV5 ASL09 ... ASL16 50...133 RV5/133 1SBN050010R1001 2 0.015
110...250 RV5/250 1SBN050010R1002 2 0.015
250...440 RV5/440 1SBN050010R1003 2 0.015
AS09 ... AS16 24...50 – – RC5-1/50 1SBN050100R1000 2 2 0.012
1SBN050100R1001
50...133
RC5-1/133
1SBC101034F0014 110...250 – – RC5-1/250 1SBN050100R1002 2 2 0.012
0.012
1SBN050100R1003
0.012
RC5-1/440
250...440
12...32
ASL09 ... ASL16
0.015
1SBN050020R1001
RT5/65
25...65 – – RT5/32 1SBN050020R1000 2 2 0.015
BEA16-3 50...90 – RT5/90 1SBN050020R1002 2 0.015
77...150 – RT5/150 1SBN050020R1003 2 0.015
150...264 – RT5/264 1SBN050020R1004 2 0.015
Connecting links with manual motor starters
1SBC101071F0014 For contactors Manual motor Type Order code Pkg Weight
starter
(1 pce)
qty
kg
AS09 … AS16
MS132-0.16 ... MS132-16
ASL09 … ASL16 MS116-0.16 ... MS116-16 BEA16-3 1SBN081006T1000 10 0.019
Connection sets for reversing contactors
BER16C-3
For contactors Mechanical Type Order code Pkg Weight
interlock unit qty (1 pce)
kg
AS09 … AS16, ASL09 … ASL16 with or without VM3 BER16C-3 1SBN081012R1000 1 0.035
Note: BER16C-3 connection set includes two BB3 fixing clips, and an electrical interlocking when fitted on contactors with built-in
N.C. auxiliary contacts. BER16C-3 can be used with or without VM3 mechanical interlock unit.
1SBC101070F0014 Connection sets for star-delta starting
Mech. interlock unit
For contactors
(1 pce)
qty
between Star & Delta Type Order code Pkg Weight
contactors
kg
AS09 … AS12, ASL09 … ASL12 with or without VM3 BEY16C-3 1SBN081018R2000 1 0.041
BEY16C-3
Note: BEY16C-3 connection set includes two BB3 fixing clips, and an electrical interlocking when fitted on Star and
Delta contactors with built-in N.C. auxiliary contacts. BEY16C-3 can be used with or without VM3 mechanical interlock unit.
