11/46 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
carat®
Accessories

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Mounting set carat® flat ) ) Mounting set carat® flat
2
1
For flat flush-mounted installation, stonework For flat flush-mounted installation, concrete
Suitable for cover frame carat®. construction
Set consists of a flush-mounted box for brickwork 3040. Suitable for cover frame carat®.
With plastering moulding tool and positioning device. Suitable for prefabricated and in-situ concrete directly
With integrated RFID-chip for easy detection. onto the formwork.
With vertically adjustable rotary ring. Set consists of a flush-mounted box for concrete walls
With Torx/slotted screws. 3060.
With variable basement depth. Delivered with a lid with distance positioning device.
Mounting boxes are combinable directly. Fixing exclusively and directly to formwork by nailing or
With flex knockouts for cables or pipes. hot gluing.
The boxes need to be plastered. With Torx/slotted screws.
Hole size : 82 mm Mounting boxes are combinable directly.
Protection class (Device): IP 20 With flex knockouts for pipes.
Protection class (Device): IP 20
1gang
3048/11 2CKA001740A0066 1/30 1gang
3068/11 2CKA001740A0088 1
2gang
3048/21 2CKA001740A0067 1 2gang
3068/21 2CKA001740A0089 1
3gang
3gang
3048/31 2CKA001740A0068 1
3068/31 2CKA001740A0090 1
4gang
4gang
3048/41 2CKA001740A0069 1
11
3068/41 2CKA001740A0091 1
1) RFID = Radio Frequency IDentification
2) Not suitable for fixing claws.
Compensation rings for flush-mounted boxes
Mounting set carat® flat For additional compensation for too deep mounted
For flat flush-mounted installation, hollow wall flush-mounted boxes.
Suitable for cover frame carat®. Adjustment height: 2,6 mm
For double planking. Protection class (Device): IP 20
Set consists of a flush-mounted box for cavity walls
3050.
With positioning device and adapter rings. 3057 2CKA001740A0081 10
Suitable for drywalls and plasterboards for 9,5 mm, 10
mm and 12,5 mm. RFID-Detector ) 1
With Torx/slotted screws. To recover of RFID-chips.
Mounting boxes are combinable directly. Power supply: 9V alkaline cell (included in delivery).
With flex knockouts for cables or pipes. Protection class (Device): IP 20
Fast installation via cable strap latches.
A 74 mm diameter moulding cutter with countersink is
needed.
Hole size : 74 mm 3049 2CKA001740A0070 1
Protection class (Device): IP 20 1) RFID = Radio Frequency IDentification
1gang
3058/11 2CKA001740A0077 1
2gang
3058/21 2CKA001740A0078 1/20
3gang
3058/31 2CKA001740A0079 1
4gang
3058/41 2CKA001740A0080 1
