11/44 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
carat®
WaveLINE control elements

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Wall-mounted transmitter WaveLINE ) ) Wall-mounted transmitter WaveLINE ) )
2
2
1
1-channel 4-channel
1gang wall-mounted transmitter independent of mains 4gang wall-mounted transmitter independent of mains
power supply. power supply.
With labelling field and labelling strip. With labelling field and labelling strip.
For switching and dimming. For switching and dimming.
For controlling blinds and light scenes. For controlling blinds and light scenes.
1 radio channel can be operated or up to 2 light scenes 4 radio channels can be operated or up to 8 light scenes
can be called up. can be called up.
For flush-mounted WaveLINE actuators 6701-101, 6702, For flush-mounted WaveLINE actuators 6701-101, 6702,
6703, 6704 and 6705-101. 6703, 6704 and 6705-101.
For LED display WaveLINE 6730-xxx. For LED display WaveLINE 6730-xxx.
Compatible with WaveLINE KNX gateway TP-RF 6770. Compatible with WaveLINE KNX gateway TP-RF 6770.
Send frequency: 868 MHz. Send frequency: 868 MHz.
Free-field range: approx. 100 m. Free-field range: approx. 100 m.
Power supply: lithium button cell battery Type CR2032. Power supply: lithium button cell battery Type CR2032.
Battery service life: typically 5 years, therefore Battery service life: typically 5 years, therefore
practically maintenance-free. practically maintenance-free.
Automatic monitoring of battery life. Automatic monitoring of battery life.
Including fixing plate for mounting on smooth walls or Including fixing plate for mounting on smooth walls or
on switch boxes. on switch boxes.
Control element: rocker switch left/right Control element: rocker switch left/right
Display elements: LED to indicate the transmission Display elements: LED to indicate the transmission
Rated voltage: 3 V- Rated voltage: 3 V-
Protection class (Device): IP 20 Protection class (Device): IP 20
Temperature range (Device): -5 °C to 45 °C Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 63 mm x 63 mm x 16 mm Dimensions: (L x W x D): 63 mm x 63 mm x 16 mm
11
ivory white 6731-82-500 2CKA006730A0032 1/10 ivory white 6733-82-500 2CKA006730A0034 1/10
aluminium 6731-83-500 2CKA006730A0035 1/10 studio white 6733-84-500 2CKA006730A0040 1/10
silver ) 1) Battery included in delivery.
3
studio white 6731-84-500 2CKA006730A0038 1/10 2) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
1) Battery included in delivery.
2) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com. WaveLINE LED display )
1
3) Surface painted.
For status display of window handle positions: open =
red, closed = green, tilted = yellow.
Wall-mounted transmitter WaveLINE ) ) Direct onsite operation possible for switching /
1
2
2-channel dimming an electrical device depending on the flush-
2gang wall-mounted transmitter independent of mains mounted insert.
power supply. 4 individual LED display channels.
With labelling field and labelling strip. Up to 8 WaveLine transmitters can be taught-in on each
For switching and dimming. LED display channel.
For controlling blinds and light scenes. Up to 8 WaveLine transmitters can be taught-in on
2 radio channels can be operated or up to 4 light scenes onsite operation.
can be called up. After a power cut all LED-Display channels light in red.
For flush-mounted WaveLINE actuators 6701-101, 6702, The cyclic telegram repeat of the WaveLINE window
6703, 6704 and 6705-101. position sensor 6720-xxx sensor automatically updates
For LED display WaveLINE 6730-xxx. the window open state.
Compatible with WaveLINE KNX gateway TP-RF 6770. Status display for depleted WaveLINE transmitter
Send frequency: 868 MHz. battery.
Free-field range: approx. 100 m. Status display for faulty transmission link and defective
Power supply: lithium button cell battery Type CR2032. WaveLINE transmitter.
Battery service life: typically 5 years, therefore User-friendly start-up without PC / software.
practically maintenance-free. Printed labelling sheet with 8 different inlay sheets.
Automatic monitoring of battery life. For WaveLINE window position sensor 6720-6x.
Including fixing plate for mounting on smooth walls or For WaveLINE 6721-xx universal signalling unit.
on switch boxes. For Busch-Watchdog 220 WaveLINE 6747 AGM.
Control element: rocker switch left/right For Busch-Universal relay switch insert 6404 U.
Display elements: LED to indicate the transmission For universal dimmer switch insert 6595 U.
Rated voltage: 3 V- Free-field range: approx. 100 m.
Protection class (Device): IP 20 Send/receive frequency: 868 MHz.
Temperature range (Device): -5 °C to 45 °C Protection class (Device): IP 20
Dimensions: (L x W x D): 63 mm x 63 mm x 16 mm Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 63 mm x 63 mm
ivory white 6732-82-500 2CKA006730A0033 1/10
anthracite 6730-81 2CKA006730A0014 1
studio white 6732-84-500 2CKA006730A0039 1/10
ivory white 6730-82 2CKA006730A0015 1
1) Battery included in delivery.
2) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com. studio white 6730-84 2CKA006730A0017 1
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
