carat®
Busch-Infoline® Accessories

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Cover plate ) ) Extension of claws )
2
1
1gang, with labelling field For the installation of flush-mounted SCHUKO® socket
With operating knob. outlets and also switches, push-buttons, etc. and deeply
For signal/cancel push-button 1520/1 UK. installed flush-mounted boxes.
For monitoring unit 1511 U. Protection class (Device): IP 20
For Busch-Leakage guard insert 1531 U.
With labelling field 61 x 20 mm.
Protection class (Device): IP 20 2148 2CKA002148A0120 100
Dimensions: (L x W x D): 63.5 mm x 63.5 mm x 11.1 mm 1) Not suitable for types 2000/3 US, 2000/6/2 US, 2000/6/6 US-101 and double
socket outlets.
studio white 1571 CN-84 2CKA001582A0346 10
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Can also be used for Busch-axcent®, solo®, and carat®. Braille symbol
self-adhesive (transparent) for cover 2506-xxx
Protection class (Device): IP 20
Cover plate ) )
2
1
2gang, with labelling field
With operating knob.
For signal push-button insert 1520/1 UKZ.
With labelling field 61 x 20 mm. light
Protection class (Device): IP 20
Dimensions: (L x W x D): 63.5 mm x 63.5 mm x 11.1 mm 2144 LI 2CKA001714A0295 10/1000
studio white 1572 CN-84 2CKA001582A0348 10 bell
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2144 KI 2CKA001714A0296 10/1000
2) Can also be used for Busch-axcent®, solo®, and carat®.
key 11
1
2
Cover plate ) ) 2144 TR 2CKA001714A0297 10/1000
with red and neutral light panel and labelling field
For Alarm Control Unit insert 1515 U-12.
For Busch-Alarm signal insert 1563 U-12. Braille symbol
For indication lamp insert 1564 U-1x. socket outlet
With labelling field 61 x 61 mm. self-adhesive, transparent for SCHUKO® socket outlets
Protection class (Device): IP 20 with hinged lid 20 EUK-xxx
Dimensions: (L x W x D): 63.5 mm x 63.5 mm x 11.1 mm Protection class (Device): IP 20
studio white 1573 CN-84 2CKA001582A0350 10
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com. 2144 ST 2CKA001714A0298 10/1000
2) Can also be used for Busch-axcent®, solo®, and carat®.
DIN A 4 labelling sheet )
1
Cover plate ) ) plastic foil
2
1
6gang, illuminable, with labelling field Suitable for all to be labeled Busch-Jaeger devices.
For signal panel insert 1566 U. For laser printer.
With labelling field 61 x 61 mm. The text of the foil is printed via the Busch-Jeager
Protection class (Device): IP 20 labeling service.
Dimensions: (L x W x D): 63.5 mm x 63.5 mm x 11.1 mm
translucent 1799/02 2CKA001799A0959 1
studio white 1575 CN-84 2CKA001582A0353 10 transparent 1799/03 2CKA001799A0960 1
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
1) 1 piece = 1 sheet.
2) Can also be used for Busch-axcent®, solo®, and carat®.
RC suppressor
Cover plate ) ) For protection against the damage or destruction of
1
2
with labelling field electronic devices due to overvoltages.
For power supply insert 1518 U. For wiring network-interconnected inductivities (e.g..
For relay insert 1539 U. relay, protection, fluorescent lamps, transformers, etc.).
For signal generator insert 1561 U-.... Eliminates functional disturbances on electronic
With labelling field 61 x 61 mm. devices, e.g. automatic circuit reclosure (clocking) of a
Protection class (Device): IP 20 movement detector.
Dimensions: (L x W x D): 63.5 mm x 63.5 mm x 11.1 mm
Dimensions: diameter 25 mm, length 35 mm, length of
studio white 1576 CN-84 2CKA001582A0355 10 the connecting cable approx. 100 mm.
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com. Rated voltage: 230 V~, +10 % / -10 %
2) Can also be used for Busch-axcent®, solo®, and carat®. Rated frequency: 50 Hz
6899 2CKA006899A0231 10
