carat®
Room thermostats

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
1
Room thermostat, flush-mounted ) ) Cover plate
Change-over contact, setpoint indication, timer, for room thermostat
remote sensor For room thermostats 1094 U, 1097 U.
With change-over contact.
Easy adjustment using menu and text-based display.
4 switching times per day can be user-defined for each
day of the week.
With fixing claws. anthracite 1794-81 2CKA001710A3629 10
Automatic summer/wintertime switch-over ivory white 1794-82 2CKA001710A3543 10
Remote sensor cable length: 4 m. studio white 1794-84 2CKA001710A3544 10
Sensor =NTC, 10 kilo-ohm at 25 degrees C.
Power reserve > 10 hours
To fit cover plate 6435-xxx. Cover plate
Class of temperature controller 1 for room thermostat
Contribution to space heating energy efficiency 1,0%. With sliding switch for nightly room temperature
Rated voltage: 230 V~ reduction. To activate nighttime mode and reduction
Rated current: 16 A of room temperature by 4K, for thermostats 1095 U,
Temperature range (Device): 10 °C to 50 °CEN 60730-2-9 1096 U and 1095 UF.
1098 UF-101 2CKA001032A0509 1/10
anthracite 1795-81 2CKA001710A3630 10
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall ivory white 1795-82 2CKA001710A3568 10
or 3060 wallbox concrete) studio white 1795-84 2CKA001710A3569 10
2) Servo valves of "closed or open when de-energized“ design are required for the
controller. E.g. article no. 6164/10-101.
Cover plate
for room thermostat
Room thermostat, flush-mounted ) ) ) For room thermostats 1094 UTA, 1097 UTA.
2
3
1
11
Heating/cooling
With separate connection (230 V~) for external
switchover between heating or cooling.
Switch contact opens when the set temperature is
reached. anthracite 1794 TA-81 2CKA001710A3695 10
With fixing claws.
Nominal current: 10 A heating ivory white 1794 TA-82 2CKA001710A3696 10
Nominal current: 5 A cooling studio white 1794 TA-84 2CKA001710A3698 10
Class of temperature controller 1
Contribution to space heating energy efficiency 1,0%.
Rated voltage: 230 V~ Cover plate
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9, for room thermostat
British Standard EN 60669-2-1 With sliding switch for nightly room temperature
reduction.
1099 UHK 2CKA001032A0515 1/10 For room thermostats 1095 UTA, 1096 UTA.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete) anthracite 1795 TA-81 2CKA001710A3722 10
2) Servo-valves, "closed when de-energized", are necessary for connection to ivory white 1795 TA-82 2CKA001710A3723 10
thermostat. e.g. Article No. 6164/10-, see KNX chapter.
3) Switching temperature difference: ± 0.5 K. studio white 1795 TA-84 2CKA001710A3725 10
Room thermostat, flush-mounted ) ) ) Cover plate
3
2
1
Heating/cooling, sliding switch For comfort timer control element 6455-101-500.
With built-in sliding switch for switchover between For standard timer control element 6456-101.
cooling or heating. For room thermostats 1098 U-101 and 1098 UF-101.
Switch contact opens when the set temperature is For short-time timer 6465 U-101.
reached. For Busch-CO2 sensor 1091 U-500.
With fixing claws.
Nominal current: 10 A heating anthracite 6435-81 2CKA006430A0303 10
Nominal current: 5 A cooling ivory white 6435-82 2CKA006430A0304 10
Class of temperature controller 1 studio white 6435-84 2CKA006430A0306 10
Contribution to space heating energy efficiency 1,0%.
Rated voltage: 230 V~
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9, Cover plate
British Standard EN 60669-2-1 for room thermostat
1099 UHKEA 2CKA001032A0516 1/10 For room temperature controller 1099 UHK.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2) Servo-valves, "closed when de-energized", are necessary for connection to
anthracite 1795 HK-81 2CKA001710A4013 10
thermostat. e.g. Article No. 6164/10-, see KNX chapter.
ivory white 1795 HK-82 2CKA001710A4015 10
3) Switching temperature difference: ± 0.5 K.
studio white 1795 HK-84 2CKA001710A4017 10
