11/68 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Busch-dynasty®
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Data-connection box, RJ 45, cat. 6a iso, shielded ) Satellite co-axial outlets Radio/TV/SAT
1
2 x outlets, 8/8-pole 3gang dead-end feeder
With down-leading outlet and LSA self-cutting clamps. Broadband technology 47-2.150 MHz.
RJ-45 terminals for networks according to Cat 6A, Class SAT connection designed as screwable F-male plug.
EA (10 Gbits/s / 500MHz). with remote feed via F-bush
Equates to cat. 6a, Class EA according to For DVB-T and broadband-cable-systems.
ISO/IEC 11801:2011-06. For analogue and digital transmission.
Terminal marking A and B according to TIA/EIA-568-B.2. With claw.
Typ according to EN 60 603-7-51:2011-01. Minimal installation depth, class A.
Shielding according to DIN EN 55022, Class B. Protection class (Device): IP 20
Up to 500 MHz on all pairs of wires. 0232-101-500 2CKA000230A0463 10/100
Suitable for 10-Gigabit Ethernet.
Suitable for PoE+ according to IEEE 802.3at, >- 1.000
contact durability. Terminating resistor
Flex cable entries from all sides without buckles. 75 Ohm
Earthing of housing via 6,3 mm blade terminal at the Protection class (Device): IP 20
back possible.
Re-embedded proofed.
Suitable for Mix-and-Match operation.
Suitable for RJ 11, RJ 12 und RJ 45.
For data cables with a diameter of 6 -10 mm. 0239 2CKA000230A0201 10/100
For trunk systems, flush-mounted wall boxes and
underfloor systems. 1 2
For wires of AWG 24-22. Mounting plate ) )
Without claws. with green insert
Mounting depth: 31 mm. For 2 modular jack inserts.
Protection class (Device): IP 20 For systems: CommScope (AVAYA / AT&T / Lucent
11
Technologies), GigaSPEED, PowerSUM, 360 GS 10E bis
0218/12-101 2CKA000230A0411 1/10 MGS 600-BK, M1 BH-xx, MPS 100E-xx.
1) Suitable for cover plate 1803-02-xxx. With R&M adapter R310694 suitable for R&M connection
modules R305111, R305112, R305113 and R305114.
Pitch dimensions: (WxH) approx. 16.9 x 17.9 mm.
Universal data connection box 8(6)/ telephone unit Without claws.
6F+N - connection box ) 1 Protection class (Device): IP 20
2 x 6-pole
with straight outlet, 1810-500 2CKA001753A9974 10/100
with screw contacts, 1) Compatibility with other manufacturers not listed is to be checked in accordance
Universal data-connection boxes: RJ 11/12, with specified snap-in dimensions.
2) For further information, please refer on the Internet.
ISDN capable Cat. 3 in acc. with IEC 603-7/German
Standard DIN EN 60603-7,
Telecommunication outlet (telephone unit ): for 1 Mounting plate ) )
2
1
telephone, 1 auxiliary device or 1 data transmission unit, with red insert
With claw. For 2 modular jack inserts.
Protection class (Device): IP 20
Suitable for Art. Nos. 0210, 0211 and 0219-101.
white UAE 8(6)TAE 6 F+N 2CKA000230A0381 10/100 For systems: AMP / tyco Electronics, BTR, EFB, Krone,
Panduit, Quante, Radiall, Setec, Dr.-Ing. Sieger, Telena,
1) Suitable for cover plate 2539-xxx, 1766-xxx and 1746-2xx-FN.
Thomas & Betts
For Telegärtner AMJ/UMJ connection modules/
Satellite co-axial outlets couplings.
2 connectors/dead-end feeder For 2 fiber optic modules of the following types:
Broadband technology 5-2.400 MHz 3M-Volition, Krone, mvk.
For DVB-T, satellite and broad-band cable systems. Pitch dimensions: (WxH) approx. 14.8 x 19.4 mm.
For analogue and digital transmission. Without claws.
With claw. Protection class (Device): IP 20
Minimal installation depth, class A. 1812-500 2CKA001753A9972 10/100
Protection class (Device): IP 20
1) Compatibility with other manufacturers not listed is to be checked in accordance
0230-101 2CKA000230A0250 10/100 with specified snap-in dimensions.
2) For further information, please refer on the Internet.
Antenna socket insert Radio/TV
2 connectors/loop through type
Broadband technology 5-2.400 MHz
For DVB-T, satellite and broad-band cable systems.
For analogue and digital transmission.
With claw.
Minimal installation depth, class A.
Protection class (Device): IP 20
0231-101 2CKA000230A0268 10/100
