Busch-dynasty®
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
WLAN access point, flush-mounted ) ) Universal data connection box with down-leading
1
power supply from mains power outlet )
1
Operation as WLAN access point for the connection of 2 x outlets, 8/8-pole
WLAN terminal devices to the LAN. With down-leading outlet.
Operation as WLAN repeater for extending the For 8-pole plug, RJ 11/12, RJ 45, ISDN capability, Cat. 3.
transmission range of a WLAN. Design according to IEC 60 603-7-2:2007.
Operation as WLAN adapter for integrating Ethernet Screw contacts
terminal devices into a WLAN. With claw.
Supports WLAN standards IEEE 802.11b/g/n with Protection class (Device): IP 20
2.4 GHz; integrated WLAN antenna. 0215 2CKA000230A0243 10
Backward connection of an Ethernet cable via screw
terminals (10/100 Mbit/s). Mounting 35 mm deep flush 1gang
Front-side Ethernet connection via a RJ45 socket boxes: or Dual Box 3070-2/35 BSDB.
(10/100 Mbit/s). 2gang product 2gang combination with adapter plate
The three connections (WLAN, Ethernet/screw terminals combinations: APBS in Dual Box only.
and Ethernet/RJ45)can be used in parallel via the
integrated switch. neon indicator: not applicable
Power supply via 2-pole connecting terminal. 1) Suitable for cover plate 1803-02-xxx.
Nominal voltage: 100 - 240 V~
For mounting in commercially available deep flush- 1
mounted and hollow-wall boxes. Data-connection box, RJ 45, cat. 6a iso, shielded )
Rated frequency: 50 Hz - 60 Hz 1gang
Protection class (Device): IP 20 With down-leading outlet and LSA self-cutting clamps.
RJ-45 terminals for networks according to Cat 6A, Class
8186/31-101-500 2CKA008100A0359 1 EA (10 Gbits/s / 500MHz).
1) Suitable for cover plate 1803-xxx. Equates to cat. 6a, Class EA according to
2) Not to be mounted in SM box 1701-xxx, 1702-xxx, 1703-xxx. ISO/IEC 11801:2011-06. 11
Terminal marking A and B according to TIA/EIA-568-B.2.
Typ according to EN 60 603-7-51:2011-01.
Reset magnet Shielding according to DIN EN 55022, Class B.
For resetting WLAN access point UP 8186/31-101 and Up to 500 MHz on all pairs of wires.
WLAN access point PoE UP 8186/41 to the factory Suitable for 10-Gigabit Ethernet.
settings. Suitable for PoE+ according to IEEE 802.3at, >- 1.000
Protection class (Device): IP 20 contact durability.
Flex cable entries from all sides without buckles.
Earthing of housing via 6,3 mm blade terminal at the
8186/11-500 2CKA008100A0361 1
back possible.
Re-embedded proofed.
Universal data connection unit, cat. 3 ) Suitable for Mix-and-Match operation.
1
1gang Suitable for RJ 11, RJ 12 und RJ 45.
With down-leading outlet. For data cables with a diameter of 6 -10 mm.
For 8-pole plug, RJ 11/12, RJ 45, ISDN capability, Cat. 3. For wires of AWG 24-22.
Design according to IEC 60 603-7-2:2007. For trunk systems, flush-mounted wall boxes and
Screw contacts underfloor systems.
With claw. Without claws.
Protection class (Device): IP 20 Mounting depth: 31 mm.
Protection class (Device): IP 20
0213-500 2CKA000230A1549 10/100
0218/11-101 2CKA000230A0409 1/10
1) Suitable for cover plate 1803-xxx.
1) Suitable for cover plate 1803-xxx.
Universal data connection box with down-leading
outlet )
1
2gang internally parallel connected
With down-leading outlet.
For 8-pole plug, RJ 11/12, RJ 45, ISDN capability, Cat. 3.
Design according to IEC 60 603-7-2:2007.
Screw contacts
With claw.
Protection class (Device): IP 20
0214 2CKA000230A0235 10/100
Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
neon indicator: not applicable
1) Suitable for cover plate 1803-02-xxx.
