11/64 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Busch-dynasty®
Blind control / timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Busch-Blind control II switch insert ) Rocker
Suitable for blind, roller blind and awning drives with with marking
mechanical or electronic limit switch shut-off. As cover for flush-mounted blind control switch/push
With two 230 V multi-way input terminals (Up/Down) switch.
for group control. With operating mode switch for the For inserts 2000/4 and 2020/4 US.
following modes: normal, louvre, base station, position.
With party function (disables the local control unit)
in combination with Busch-Blind control II control anthracite 1785 JA-81 2CKA001751A2934 10
cover 6430-xx-xxx, 6066-xx-xxx. Wind alarm, cleaning ivory white 1785 JA-82 2CKA001751A2748 10
functions can be accommodated via extension input. antique brass ) 1785 JA-840-500 2CKA001751A3120 10
1
For control cover 6430-xx-xxx. For IR control element
6066-xx-xxx. For comfort timer control element 1) Real metal surface refined by hand.
6455-101-500.
Running time: 3 min Cover plate
Rated voltage: 230 V~, +10 % / -10 % with rotary control, with marking
Rated frequency: 50 Hz As cover for flush-mounted blind control switch/push
Outputs: 2x Normally open contact switch.
Rated current: 3 A, cos φ 0.5 For inserts 2712 U, 2713 U and 2722 U, 2723 U.
Rated power: 690 VA
Control/Signal outputs: 2 anthracite 1740-81 2CKA001710A3623 10
Temperature range (Device): 0 °C to 35 °C
ivory white 1740-82 2CKA001710A3154 10
6411 U-500-101 2CKA006410A0378 1/10
antique brass ) 1740-840-500 2CKA001710A4089 1/10
1
1) Compatible with types 6411 U/x.
1) Real metal surface refined by hand.
Brightness sensor Control element
11
For insert 6411U/S-101. For Busch-Blind control II insert 6411 U-101,
With 2 m connecting cable. 6411 U/S-101.
Measuring range: 15-50,000 lux.
For basic blind insert 6418 U.
For Busch-Universal 2gang 1way insert 6402 U.
6414-101 2CKA006410A0389 1/10
anthracite 6430-81-102 2CKA006430A0326 1/10
ivory white 6430-82-102 2CKA006430A0327 1/10
Sun sensor antique brass ) 6436-840-500 2CKA006430A0406 1/10
1
For insert 6411U/S-101.
Measuring range: 5-50,000 lux. 1) Real metal surface refined by hand.
Cover plate )
1
with rotary knob
6482 2CKA006410A0203 1 For comfort blinds insert 6419 U.
Busch-Short-time timer insert ) 1
countdown timer
For time-programmed switching of electrical anthracite 6436-81 2CKA006430A0387 10
consumers. With control cover, without cover plate. ivory white 6436-82 2CKA006430A0356 10
Minimum timer time: 1 second. antique brass ) 6436-840-500 2CKA006430A0406 1/10
2
Maximum timer time: 9:59:59 hours.
Rated voltage: 230 V~, +10 % / -10 % 1) Continuous lighting of the turn knob possible using glow lamp 3855. Not included
in delivery. Neutral wire required for operation with neon lamp.
Rated frequency: 50 Hz 2) Real metal surface refined by hand.
Outputs: 1x Normally open contact
Rated current: 10 A, cos φ 1
Rated power: 2300 VA
Temperature range (Device): 0 °C to 35 °CIEC 60669-2-1,
British Standard EN 60669-2-1
6465 U-101-500 2CKA006410A0393 1/10
Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
Cover frames: 1gang frame 1721 BS-2xG
or Dual Box frame 1722 BSDB-2xG.
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
neon indicator: not applicable
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
