11/66 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Busch-dynasty®
Socket outlets

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

SCHUKO® socket outlet ) SCHUKO® socket outlet
1
shuttered with hinged lid
With screwless terminals. With screwless terminals.
DP (2 P + E) DP (2 P + E)
Rated voltage: 250 V~ Hinged lid notches when opened.
Rated current: 16 A Rated voltage: 250 V~
Rated current: 16 A
anthracite 20 EUCKS-81 2CKA002013A5265 10
ivory white 20 EUK-82 2CKA002018A1465 10
ivory white 20 EUCKS-82 2CKA002013A5244 10/100
antique brass ) 20 EUK-840-500 2CKA002018A1515 10
1
antique brass 20 EUCKS-845-500 2CKA002013A5401 10
anthracite ) 1) Real metal surface refined by hand.
2
antique brass 20 EUCKS-848-500 2CKA002013A5398 10/100
ivory white ) SCHUKO® USB socket outlet ) ) )
2
1
3
2
shuttered
1) Increased shock protection .
2) Real metal surface refined by hand. With screwless terminals.
Shuttered.
DP (2 P + E)
SCHUKO® socket outlet ) For supply and support of mobile devices via USB-cable.
1
shuttered With USB female connector type A.
With screw-type terminals. With electronic short-circuit protection.
DP (2 P + E) With electronic overload protection.
Rated voltage: 250 V~ Simultaneous charging via USB connection and use of
Rated current: 16 A the SCHUKO® socket outlet.
Rated voltage: 250 V~
antique brass 23 EUCKS-845-507 2CKA002011A6247 10 Secondary: 5 V-, +5 % / -5 %
anthracite )
2
Rated frequency: 50 Hz
11
antique brass 23 EUCKS-848-507 2CKA002011A6245 10 Suitable for: SCHUKO® socket outlet
ivory white ) Rated current: 16 A
2
anthracite ) 2300 EUCB-81 2CKA002013A5448 10 Suitable for: USB connection
3
Rated current: 700 mA
3
ivory white ) 2300 EUCB-82 2CKA002013A5449 10/100 Protection class (Device): IP 20, SELV
1) Increased shock protection . Temperature range (Device): 5 °C to 35 °C
2) Real metal surface refined by hand. Dimensions: (L x W x D): 71 mm x 71 mm x 53 mm
3) With screw-type terminals
Mounting depth: 35 mm
anthracite 20 EUCBUSB-81-500 2CKA002011A6176 1
SCHUKO® socket outlet steplight® ) ivory white 20 EUCBUSB-82-500 2CKA002011A6177 1
1
With night orientation light
4
with separate connection cables for switch contact. antique brass ) 20 EUCBUSB-840-5002CKA002011A6246 1
with LED, 1) Connecting terminals approved in accordance with VDE 0620-1 as connectors.
Shuttered. 2) No data transfer.
DP (2 P + E) 3) Use dust cover 2098 when cleaning the device.
Rated voltage: 250 V~ 4) Plastic surface refined by hand.
Rated current: 16 A
ivory white 20 EUCBLI-82 2CKA002013A5292 1
2
antique brass ) 20 EUCBLI-840-500 2CKA002013A5399 1
1) Connecting terminals approved in accordance with VDE 0620-1 as connectors.
2) Plastic surface refined by hand.
13 A Switched socket outlet
1gang
With screw-type terminals.
SP switched
Without claws.
Only for mounting in VDE flush-mounted wallboxes CFB
122 and CFBM 122.
Rated voltage: 250 V~
Rated current: 13 ABS 1363: part2
anthracite 2190 EUC-81 2CKA002190A0216 10/100
ivory 2190 EUC-82 2CKA002190A0213 10/100
antique brass ) 2190 EUC-840-500 2CKA002190A0222 10
1
1) Surface painted.
