Busch-dynasty®
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Mounting plate ) ) Channel assembly adapter
1
2
with black insert For the accommodation of one or two universal
For MTRJ or 2 modular jack inserts. modules 0219.
For systems: Ackermann, AMP / tyco Electronics (Slim For channel and under-floor installation.
Line (SL) -SM 2gang/switches: 110Connect Jacks, Suitable for telephone connection unit cover plates
Toolless Jacks / Standard 110Connect Jacks), Brand-Rex, 2539-21x and 1766-xxx.
CombiNet, EFB Electronic, Telena. Protection class (Device): IP 20
For 2 fiber optic modules of the following types: AMP / 0219/13 2CKA000230A0396 1/10
tyco Electronics MTRJ.
Pitch dimensions: (WxH) approx. 14.8 x 20.4 mm.
Without claws. Universal module, RJ 45, cat. 6a iso, shielded )
1
Protection class (Device): IP 20 1gang
1814-500 2CKA001753A9973 10/100 For installation in installation adapter 0219/12 or
0219/13.
1) Compatibility with other manufacturers not listed is to be checked in accordance
with specified snap-in dimensions. Also suited for mounting into cover plate 2561-xxx,
2) For further information, please refer on the Internet. 2564-02-xxx and bases 1812, 1866 EB, and 1867 EB.
RJ-45 terminals for networks according to Cat 6A, Class
EA (10 Gbits/s / 500MHz).
Mounting plate ) ) Equates to cat. 6a, Class EA according to
2
1
with blue insert ISO/IEC 11801:2011-06.
For 2 modular jack inserts. Cat. 6A according to ISO/IEC 11801: 2011-06.
For system: ITT Cannon RJ45 Cat. 5 type 808 RJ45 Terminal marking A and B according to TIA/EIA-568-B.2.
Mark III. Typ according to EN 60 603-7-51:2011-01.
Pitch dimensions: (WxH) approx. 16.0 x 11.0 mm. Shielding according to DIN EN 55022, Class B.
Without claws. Suitable for PoE+ according to IEEE 802.3at, >- 1.000
Protection class (Device): IP 20 contact durability. 11
1816 2CKA001710A3100 10/100 Bend-radius optimised cable feed (30°).
Earthing of housing via 6,3 mm blade terminal at the
1) Compatibility with other manufacturers not listed is to be checked in accordance back possible.
with specified snap-in dimensions. Re-embedded proofed.
2) For further information, please refer on the Internet.
Suitable for Mix-and-Match operation.
For 8-pole plug RJ 45 only.
Mounting plate ) ) Housing made from diecast zinc.
1
2
with orange base With integrated dust-protection cap (can be removed if
For 2 modular jack inserts. necessary).
For system: LexCom 150 and LexCom 250. With insulation displacement connection
Pitch dimensions: (WxH) approx. 15.4 x 15.4 mm. For data cables with a diameter of 6 -10 mm.
Without claws. For wires of AWG 24-22.
Protection class (Device): IP 20 For trunk systems, flush-mounted wall boxes and
underfloor systems.
1819 2CKA001753A8056 10/100 Protection class (Device): IP 20
1) Compatibility with other manufacturers not listed is to be checked in accordance
0219-101 2CKA000230A0413 1/10
with specified snap-in dimensions.
2) For further information, please refer on the Internet. 1) With assembly adapters appropriate for telephone unit cover plates 2539-21x and
1766-xxx.
Mounting plate ) )
1
2
with grey base Modular-Jack insert
For 2 modular jack inserts. 6-pole Cat. 3 (AMP-No. 216000-2)
For system: Panduit MiniCom (Cu. z.B. TX6 10 Gig For cover plate 2561-xxx, 2561-02-xxx and insert 1812,
Shielded Jack modules and fiber optic modules. 1866 built-in, 1867 built-in.
Pitch dimensions: (WxH) approx. 15.9 x 18.7 mm. For conductor cross-sections of 0.12 mm² (AWG 26) to
Without claws. 0.35 mm² (AWG 22).
Protection class (Device): IP 20 Protection class (Device): IP 20
1820 2CKA001753A8057 10/100 0210 2CKA000225A0078 10
1) Compatibility with other manufacturers not listed is to be checked in accordance
with specified snap-in dimensions.
2) For further information, please refer on the Internet. Modular-Jack insert
8-pole Cat. 3 (AMP-No. 216005-4)
For cover plate 2561-xxx, 2561-02-xxx and insert 1812,
Flush-mounted assembly adapter 1866 built-in, 1867 built-in.
For the accommodation of one or two universal For conductor cross-sections of 0.12 mm² (AWG 26) to
modules 0219. 0.35 mm² (AWG 22).
For flush-mounted installation. Protection class (Device): IP 20
Suitable for telephone connection unit cover plates 0211 2CKA000225A0086 10
2539-21x and 1766-xxx.
Protection class (Device): IP 20
0219/12 2CKA000230A0395 1/10
