Busch-dynasty®
Room thermostats

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
2
Room thermostat, flush-mounted ) ) ) Room thermostat, flush-mounted ) ) ) 3
1
2
3
Switch contact opens when the set temperature is Sliding switch, 24 V
reached. With built-in slide switch and control lamp for nightly
With fixing claws. reduction of 4 K. Switch contact opens when the set
Separate terminal to activate nighttime mode and temperature is reached. With fixing claws.
reduction of room temperature by 4K. Separate terminal to activate nighttime mode and
Class of temperature controller 1 reduction of room temperature by 4K.
Contribution to space heating energy efficiency 1,0%. Class of temperature controller 1
Rated voltage: 230 V~ Contribution to space heating energy efficiency 1,0%.
Rated current: 10 A Rated voltage: 24 V~
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9, Rated current: 1 A
British Standard EN 60669-2-1 Temperature range (Device): 5 °C to 30 °CEN 60730-2-9,
British Standard EN 60669-2-1
1094 U-500 2CKA001032A0512 1/10
Mounting 35 mm deep flush 1gang 1096 U 2CKA001032A0485 1
boxes: or Dual Box 3070-2/35 BSDB. Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only. 2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
or 3060 wallbox concrete) Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
2) Servo-valves, "closed when de-energized", are necessary for connection to or 3060 wallbox concrete)
thermostat. e.g. Article No. 6164/10-, see KNX chapter. 2) Servo-valves, "closed when de-energized", are necessary for connection to
3) Switching temperature difference: ± 0.5 K. thermostat, e.g., Art. No. 6164/10 .
3) Switching temperature difference: ± 0.5 K.
Room thermostat, flush-mounted ) ) ) 11
2
3
1
Slide switch Room thermostat, flush-mounted ) ) ) 3
1
2
With built-in slide switch and control lamp for nightly 1gang 2way
reduction of 4 K. With fixing claws.
Switch contact opens when the set temperature is Class of temperature controller 1
reached. Contribution to space heating energy efficiency 1,0%.
With fixing claws. Rated voltage: 230 V~
Separate terminal to activate nighttime mode and Rated current: 5 A
reduction of room temperature by 4K. Temperature range (Device): 5 °C to 30 °CEN 60730-2-9,
Class of temperature controller 1 British Standard EN 60669-2-1
Contribution to space heating energy efficiency 1,0%. 1097 U-500 2CKA001032A0513 1/10
Rated voltage: 230 V~
Rated current: 10 A Mounting 35 mm deep flush 1gang
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9, boxes: or Dual Box 3070-2/35 BSDB.
British Standard EN 60669-2-1 2gang product 2gang combination with adapter plate
1095 U-500 2CKA001032A0514 1/10 combinations: APBS in Dual Box only.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB. Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2gang product 2gang combination with adapter plate 2) Servo valves of "closed or open when de-energized“ design are required for the
combinations: APBS in Dual Box only. controller. E.g. article no. 6164/10-101.
3) Switching temperature difference: ± 0.5 K.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete) 1 2 3
2) Servo-valves, "closed when de-energized", are necessary for connection to Room thermostat, flush-mounted ) ) )
Actual value indication
thermostat. e.g. Article No. 6164/10-, see KNX chapter.
3) Switching temperature difference: ± 0.5 K. With actual value temperature display. Automatic
controller calibration. Switch contact opens when the
set temperature is reached. With fixing claws.
Separate terminal to activate nighttime mode and
reduction of room temperature by 4K.
Class of temperature controller 1
Contribution to space heating energy efficiency 1,0%.
Rated voltage: 230 V~
Rated current: 10 A
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9,
British Standard EN 60669-2-1
1094 UTA 2CKA001032A0487 1/10
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2) Servo-valves, "closed when de-energized", are necessary for connection to
thermostat. e.g. Article No. 6164/10-, see KNX chapter.
