Room thermostats

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

3
1
2
Room thermostat, flush-mounted ) ) ) Room thermostat, flush-mounted ) ) ) 3
1
2
Sliding switch, actual value indication Change-over contact, setpoint indication, timer
With actual value temperature display With change-over contact.
Automatic controller calibration Easy adjustment using menu and text-based display.
Switch contact opens when the set temperature is 4 switching times per day can be user-defined for each
reached. day of the week.
With built-in slide switch and control lamp for nightly With fixing claws.
reduction of 4 K. Automatic summer/wintertime switch-over
With fixing claws. Power reserve > 10 hours.
Separate terminal to activate nighttime mode and To fit cover plate 6435-xxx.
reduction of room temperature by 4K. Class of temperature controller 1
Class of temperature controller 1 Contribution to space heating energy efficiency 1,0%.
Contribution to space heating energy efficiency 1,0%. Rated voltage: 230 V~
Rated voltage: 230 V~ Rated current: 10 A
Rated current: 10 A Temperature range (Device): 5 °C to 30 °CEN 60730-2-9
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9, 1098 U-101 2CKA001032A0508 1/10
British Standard EN 60669-2-1
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
1095 UTA 2CKA001032A0488 1/10 Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, or 3060 wallbox concrete)
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall 2) Servo valves of "closed or open when de-energized“ design are required for the
or 3060 wallbox concrete) controller. E.g. article no. 6164/10-101.
2) Servo-valves, "closed when de-energized", are necessary for connection to 3) Switching temperature difference: ± 0.5 K.
thermostat. e.g. Article No. 6164/10-, see KNX chapter.
3) Switching temperature difference: ± 0.5 K.
Room thermostat, flush-mounted ) 1
Remote sensor
2
Room thermostat, flush-mounted ) ) ) With remote sensor and thermal feedback
1
3
11
Sliding switch, actual value indication, 24 V For underfloor heating.
With actual value temperature display With built-in slide switch and control lamp for nightly
Automatic controller calibration reduction of 4 K.
Switch contact opens when the set temperature is Switch contact opens when the set temperature is
reached. reached.
With built-in slide switch and control lamp for nightly With fixing claws.
reduction of 4 K. Remote sensor cable length: 4 m.
With fixing claws. Sensor =NTC, 10 kilo-ohm at 25 degrees C.
Separate terminal to activate nighttime mode and Adjusting range: +10 to +50° C.
reduction of room temperature by 4K. Connecting cable: 1mm² to 2.5 mm²
Class of temperature controller 1 Separate terminal to activate nighttime mode and
Contribution to space heating energy efficiency 1,0%. reduction of room temperature by 4K.
Rated voltage: 24 V~ Class of temperature controller 1
Rated current: 1 A Contribution to space heating energy efficiency 1,0%.
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9, Rated voltage: 230 V~
British Standard EN 60669-2-1 Rated current: 16 A, cos φ 1EN 60730-2-9, British
1096 UTA 2CKA001032A0489 1/10 Standard EN 60669-2-1
1095 UF 2CKA001032A0497 1/10
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
or 3060 wallbox concrete) Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
2) Servo-valves, "closed when de-energized", are necessary for connection to or 3060 wallbox concrete)
thermostat, e.g., Art. No. 6164/10 .
3) Switching temperature difference: ± 0.5 K.
Room thermostat, flush-mounted ) ) ) 3
2
1
1gang 2way
Room thermostat, flush-mounted ) ) ) With fixing claws.
1
3
2
Change-over contact, actual value indication Class of temperature controller 1
With actual value temperature display Contribution to space heating energy efficiency 1,0%.
Automatic controller calibration Rated voltage: 230 V~
With fixing claws. Rated current: 5 A
Class of temperature controller 1 Temperature range (Device): 5 °C to 30 °CEN 60730-2-9,
Contribution to space heating energy efficiency 1,0%. British Standard EN 60669-2-1
Rated voltage: 230 V~
Rated current: 5 AEN 60730-2-9, British Standard EN 1097 U-500 2CKA001032A0513 1/10
60669-2-1 Mounting 35 mm deep flush 1gang
1097 UTA 2CKA001032A0490 1/10 boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall combinations: APBS in Dual Box only.
or 3060 wallbox concrete) 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
2) Servo valves of "closed or open when de-energized“ design are required for the
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
controller. E.g. article no. 6164/10-101. or 3060 wallbox concrete)
3) Switching temperature difference: ± 0.5 K.
2) Servo valves of "closed or open when de-energized“ design are required for the
controller. E.g. article no. 6164/10-101.
3) Switching temperature difference: ± 0.5 K.
