Busch-dynasty®
Room thermostats LED light

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
1
Room thermostat, flush-mounted ) ) Info light unit ) )
1
2
Change-over contact, setpoint indication, timer, Size of information field 43 x 43 mm.
remote sensor Long service life of the lighting element (LEDs).
With change-over contact. Homogeneous backlighting of the information field.
Easy adjustment using menu and text-based display. Colour temperature 6,500 K (cold white)
4 switching times per day can be user-defined for each Power consumption: < 0.5 W
day of the week. Rated voltage: 230 V~
With fixing claws. Rated frequency: 50 Hz - 60 Hz
Automatic summer/wintertime switch-over Protection class (Device): IP 20
Remote sensor cable length: 4 m. 2062 U 2CKA001511A0115 1/10
Sensor =NTC, 10 kilo-ohm at 25 degrees C.
Power reserve > 10 hours 1) Use relay inserts when switching through movement sensors or comfort switches.
2) For switching the LED flush mounted insert use switches without orientation light
To fit cover plate 6435-xxx. only.
Class of temperature controller 1
Contribution to space heating energy efficiency 1,0%.
Rated voltage: 230 V~ Cover plate ) )
1
2
Rated current: 16 A As cover for flush-mounted info light.
Temperature range (Device): 10 °C to 50 °CEN 60730-2-9 For insert 2062 U.
1098 UF-101 2CKA001032A0509 1/10 Size of information field 43 x 43 mm.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2) Servo valves of "closed or open when de-energized“ design are required for the anthracite 1716-81 2CKA001731A1921 1
controller. E.g. article no. 6164/10-101. ivory white 1716-82 2CKA001731A1922 1
antique brass ) 1716-840-500 2CKA001731A2025 1
3
Cover plate 1) Included with the cover are 46 different text labels and symbols. 11
for room thermostat 2) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
For room thermostats 1094 U/UF, 1097 U/UF. 3) Plastic surface refined by hand.
Cover plate
for indication lamp
anthracite 1794-81 2CKA001710A3629 10 For insert 2061/2661 U.
As cover for flush-mounted light signal.
ivory white 1794-82 2CKA001710A3543 10 Protection class (Device): IP 20
antique brass ) 1794-840-500 2CKA001710A4087 10
1
1) Plastic surface refined by hand.
anthracite 1756-81 2CKA001753A0089 10
ivory white 1756-82 2CKA001753A0090 10
Cover plate
for room thermostat
With sliding switch for nightly room temperature Cap
reduction. for indication lamp
to activate nighttime mode and reduction of room For indication lamps.
temperature by 4K, for thermostats 1095 U, 1096 U and Protection class (Device): IP 20
1095 UF.
anthracite 1795-81 2CKA001710A3630 10
ivory white 1795-82 2CKA001710A3568 10 clear- 1565-11 2CKA001565A0167 10
transparent
antique brass ) 1795-840-500 2CKA001710A4088 10
1
Red 1565-12 2CKA001565A0175 10
1) Plastic surface refined by hand.
green 1565-13 2CKA001565A0183 10
