Dimmers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
3
Busch-touch dimmer ) ) ) ) Busch-touch dimmer ) ) )
1
4
3
2
1
flush mounted, RLC, 60-420 W flush mounted, 1-10V
With light-level memory and intelligence for universal 3 wire connection (neutral conductor required).
operation. For controlling ballast units for fluorescent lamps with
Selectable Soft-ON/OFF function and memory function. control output 1-10 V DC, control current max. 50 mA DC.
Capacity expansion via output-side, parallel connectable For control cover with control lamp 6543-xxx-10x.
load line with a power module 6594 U up to 735 W/VA For Busch-Remote control IR control cover 6066-xxx-10x
possible. and 6067-xxx-10x.
For incandescent lamps, 230 V tungsten halogen lamps For comfort timer control element 6455-101-500.
and low-voltage halogen lamps with conventional For Busch-Watchdog 180 flush-mounted Sensor
transformers or electronic transformers. Standard 6810-21x-101.
Short-circuit-proof, overload-protected. For Busch-Watchdog 180 flush-mounted sensor
With touch control. Comfort II 6800-xxx-104 and 6800-xxx-104M.
Operation also possible via conventional push buttons For Busch-Watchdog Presence tech 6813-xxx-101
(2020 US, 2021/6 UK). und 6813/11-xxx. Combinable with Busch-Watchdog
Without control cover. extension insert 6805 U.
For control cover with control lamp 6543-xxx-10x. Operation also possible via conventional push buttons
For Busch-Remote control IR control cover 6066-xxx-10x. (2020 US, 2021/6 UK).
For comfort timer control element 6455-101-500. For LED control via control gears
For Busch-Watchdog 180 flush-mounted Sensor Without control cover.
Standard 6810-21x-101. Rated voltage: 230 V~, +10 % / -10 %
For Busch-Watchdog 180 flush-mounted sensor Rated frequency: 50 Hz
Comfort II 6800-xxx-104 and 6800-xxx-104M. Rated power: 700 W/VA
For Busch-Watchdog Presence tech 6813-xxx-101 und IEC 60669-2-1, British Standard EN 60669-2-1
6813/11-xxx.
Combinable with Busch-Watchdog extension insert
6805 U. 6550 U-101-500 2CKA006550A0042 1
11
Rated voltage: 230 V~, +10 % / -10 % 1) Non-illuminable.
Rated frequency: 50 Hz 2) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Rated power: 60 - 420 W/VA Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
IEC 60669-2-1, British Standard EN 60669-2-1 3) with integrated making-current limiter

1
6593 U-500 2CKA006590A0171 1/10 Cover plate )
with rotary knob, with indication lamp
1) In the case of conventional transformers, take ~20% transformer loss into account.
Elevated knob.
2) In case of electronic transformers, 5 % transformer losses.
3) In conjunction with 6800-xxx-104 (M) a Soft Off can be adjusted. With transparent luminous ring.
4) Only in conjunction with standard flush-mounting boxes according to DIN 49073, For Busch-Dimmer®.
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall For inserts
or 3060 wallbox concrete) 2112 U-101/2247 U/2250 U/6513 U-102/6517 U-10x/
6519 U/6520 U/6523 U(R)(10x) /6591 U-10x and 6592 U.
Material stainless steel. Anti fingerprint.
Busch-Dimmer®, capacity booster )
1
flush mounted, RLC, 200-315 W stainless steel 6540-866-102 2CKA006599A2959 10/100
The control is effected by a Busch-Universal master 1) Replacement neon lamp, Art. No. 3855.
dimmer 6593 U or Busch-Universal rotary dimmer
6591U-101
2
1
3
For incandescent lamps, 230 V tungsten halogen lamps Control element ) ) )
and low-voltage halogen lamps with conventional with neon lamp
transformers or electronic transformers. Can be combined with LED dimmer 6524 U, and 6526 U,
Can only be installed in conjunction with a cover plate Busch-Universal touch-type controller 6550 U-10x,
2114-xxx and 6541-xxx. Busch-Memory touch dimmer 6560 U-101, Busch-
Without cover plate. Universal-Dimmer® 6593 U, Busch-Universal relay insert
Rated voltage: 230 V~, +10 % / -10 % 6401 U-10x, Busch-Universal 2gang insert 6402 U.
Rated frequency: 50 Hz Surface painted.
Rated power: 200 - 315 W/VA stainless steel 6543-866-101 2CKA006599A2926 1/10
IEC 60669-2-1, British Standard EN 60669-2-1
1) Compatible with previous type 6543-xxx.
2) Touch-type Controller 6550 U-xxx non-illuminable.
3) Replacement neon lamp 3857.
6594 U-500 2CKA006590A0172 1
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, 1
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall Control element )
or 3060 wallbox concrete) with neon lamp
Combinable with Busch-Memory 2gang dimmer 6565 U.
Material stainless steel.
Anti fingerprint.
stainless steel 6545-866 2CKA006599A2927 1/10
1) Replacement neon lamp 3857.
