11/101

—
pure stainless steel
Movement detectors / comfort switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Watchdog 180 flush-mounted comfort sensor Busch-Universal relay switch insert
II ) ) ) 3 wire connection (neutral conductor required).
1
2
3
with multi-lens For switching lighting systems. For Busch-Comfort
For automatic switching of devices dependent on switch control element 6815-...-101-500.
motion and brightness. For Busch-Presence detector sensor 6813-…-102-500.
For down-to-ground detection. Can be combined with Universal-Slave insert
For relay inserts 6401 U-102, 6402 U and 6812 U-101. 6440/05 U-500. Operation in 1gang 2way installations
For MOS-Fet insert 6804 U-101. via push switch-unit for combination with flush-
For Dimmer insert 6593 U. mounted units. Operation also possible via conventional
For extension insert 6805 U. push buttons (2020 US, 2021/6 UK).
With integrated selector switch for ON-AUTOMATIC-OFF 2 supplementary inputs via 127 V push switch
(lockable). (e.g. 2020 US), central disablement of all outputs
Soft phase-out: In combination with the 6593 U (mode possible, supplementary IR remote control is possible
of operation: Soft OFF) the illumination is dimmed via IR flying receiver 6045 E-101.
down within 60 sec and switched off. Rated voltage: 230 V~, +10 % / -10 %
Surveillance density: 28 sectors with 112 switching Rated frequency: 50 Hz - 60 Hz
segments. Outputs: 1x Normally open contact, potential-bound
Switch-off delay: 10 sec to 30 min or short-time pulse Suitable for: 230 V~ LEDi
1 sec adjustable. Rated power: 100 W/VA
Surface painted. Suitable for: 230 V incandescent lamps/230 V halogen
Detection range: frontal: 15 m, lateral: 5 m, Mounting lamps.
height: 2.5 m Rated current: 10 AX
Detection range 2: frontal: 10 m, lateral: 2.5 m, Mounting Rated power: 2300 W
height: 1.2 m Suitable for: Low voltage halogen lamps operated by
Detection angle: 180 ° transformers.
Brightness limit value: 5 Lux Up to daytime operation Rated power: 2300 VA
Mounting height: 0.8 m - 1.2 m alternative: 2.5 m Temperature range (Device): -5 °C to 45 °C 11
Protection class (Sensor): IP 20 Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm
Temperature range (Device): 0 °C to 35 °C Mounting depth: 31 mm
DIN EN 60669-2-1
stainless steel 6800-866-104M 2CKA006800A2344 1
LEDi
1) installation: slide switch top.
2) Please order the respective flush-mounted insert separately.
3) Surface painted. 6440/01 U-500 2CKA006400A0085 1
Universal e-contact insert ) 1
Cover plate ) 1
For proximity switch 6406 U. 2-wire connection (neutral conductor not required)
Surface painted. For switching lighting systems. For Busch-Comfort
switch control element 6815-...-101-500. For Busch-
Presence detector sensor 6813-…-102-500.
Can be combined with Universal-Slave insert
6440/05 U-500.
stainless steel 6476-866 2CKA006470A0009 10 Operation in 1gang 2way installations via push switch-
unit for combination with flush-mounted units.
1) Surface painted.
Operation also possible via conventional push buttons
(2020 US, 2021/6 UK).
2 supplementary inputs via 127 V push switch
(e.g. 2020 US), central disablement of all outputs
possible, supplementary IR remote control is possible
via IR flying receiver 6045 E-101
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz - 60 Hz
Outputs: 1x Normally open contact, potential-bound
Suitable for: 230 V~ LEDi
Rated power: 2 - 80 W/VA
Suitable for: 230 V incandescent lamps/230 V halogen
lamps
Rated power: 20 - 180 W
Suitable for: Low voltage halogen lamps operated by
transformers.
Rated power: 20 - 180 VA
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm
Mounting depth: 31 mm
DIN EN 60669-2-1

6440/04 U-500 2CKA006400A0088 1
1) Only use dimmable high voltage LEDs.
