11/103

—
pure stainless steel
Blind control / timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
Blind switch insert ) ) DIN profile-semi cylindrical lock
1
With rotary knob/push button. Acc. to German Standard DIN 18252.
Rated voltage: 250 V~ Total length 40 mm
Rated current: 10 A for blind switches and push switches
Protection class (Device): IP 20 For inserts 2712/2713/2722/2723/2733 USL-101 and
IEC60669-1, British Standard EN 60669-1 2712/2733 SLW-5x.
Protection class (Device): IP 20
DP )
3
2722 U 2CKA001101A0559 10 different lock mechanism, with 3 keys
SP, N, E 0520 PZ-VS 2CKA000470A0013 1/100
2723 U 2CKA001101A0567 10 lock mechanism, with 3 keys
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall 0521 PZ-GS 2CKA000470A0021 1/100
or 3060 wallbox concrete)
2) Blind switches/push switches prevents fast change over between operating 1 2 3
directions. Comfort blind insert ) ) )
3) Also suitable for controlling direct voltage drives. with memory and positioning function
For the manual and automatic control of roller blinds.
The roller blind moves to the position set using the turn
Blind switch/push-switch ) ) ) ) knob. Executes the individually programmed switching
3
4
1
2
For profile semi-cylindrical lock/switch and push-switch. commands (UP/DOWN) in a 24-hour rhythm.
Delivered without cylindrical lock. Suitable for roller blind drives with mechanical or
Rated voltage: 250 V~ electronic limit switch shut-off.
Rated current: 10 AX Suitable for operation without neutral conductor.
Protection class (Device): IP 20 Without an extension input. 11
IEC60669-1, British Standard EN 60669-1 Power reserve of 45 minutes (maintenance-free as
capacitor).
DP ) Rated voltage: 230 V~, +10 % / -10 %
5
2712 USL-101 2CKA001101A0872 10 Rated frequency: 50 Hz
Outputs: 2x Normally open contact
SP, N, E Rated current: 1.3 A, cos φ 0.5
Rated power: 300 VA
2713 USL-101 2CKA001101A0880 10
1) For installation on British Standard wallboxes please use adapter plate APBS Temperature range (Device): 0 °C to 35 °C
(6599-0-2813). (Depth of box 60 mm.)
2) Blind switches/push switches prevents fast change over between operating 6419 U 2CKA006410A0390 1/10
directions. 1) Pertinent cover plates 6436-xx.
3) Use the cylindrical lock according to the enclosed drawing. 2) N-conductor connection may be required for operation with blind and roller
4) See semi-cylindrical lock. blind drives with electronic limit switch shut-off. If no N-conductor is available,
5) Also suitable for controlling direct voltage drives. capacitor set 6498 can be used.
3) Only suitable for single unit control.
Blind switch insert ) ) ) )
1
4
3
2
1
2
For profile semi-cylindrical lock/push-button. Basic blind insert ) )
Delivered without cylindrical lock. 2-wire blind insert
Rated voltage: 250 V~ Suitable for blind and roller blind drives with mechanical
Rated current: 10 A or electronic limit switch shut-off.
Protection class (Device): IP 20 Suitable for operation without neutral conductor.
British Standard EN 60669-1, IEC60669-1 Without an extension input.
For control cover 6430-xx-xxx.
DP ) For standard timer control element 6456-101.
5
2722 USL-101 2CKA001101A0898 10 Running time: 3 min
Rated voltage: 230 V~, +10 % / -10 %
SP, N, E Rated frequency: 50 Hz
Outputs: 2x Normally open contact
2723 USL-101 2CKA001101A0906 10 Rated current: 3 A, cos φ 0.5
1) For installation on British Standard wallboxes please use adapter plate APBS Rated power: 690 VA
(6599-0-2813). (Depth of box 60 mm.)
2) Blind switches/push switches prevents fast change over between operating Temperature range (Device): 0 °C to 35 °C
directions.
3) Use the cylindrical lock according to the enclosed drawing. 6418 U-500 2CKA006410A0376 1/10
4) See semi-cylindrical lock. Mounting 35 mm deep flush 1gang
5) Also suitable for controlling direct voltage drives.
boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
1) N-conductor connection required for operation with control cover 6430-7x,
illuminated.
2) N-conductor connection may be required for operation with blind and roller
blind drives with electronic limit switch shut-off. If no N-conductor is available,
capacitor set 6498 can be used.
