11/112 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
pure stainless steel
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Channel assembly adapter Built-in jack
For the accommodation of one or two universal For potential balancing jack cover plate and installation
modules 0219. in cover plates.
For channel and under-floor installation. For devices of 19 mm diameter.
Suitable for telephone connection unit cover plates Protection class (Device): IP 20
2539-21x and 1766-xxx.
Protection class (Device): IP 20
0471-0-0037 2CKA000471A0037 10
0219/13 2CKA000230A0396 1/10
Potential balancing plug
Universal module, RJ 45, cat. 6a iso, shielded ) Suitable for plug 2095 UC-212 and built-in jack 0471-0-
1
1gang 0037 acc. to German Standard DIN 42801.
For installation in installation adapter 0219/12 or For potential balancing jack cover plate (connection up
0219/13. to 6 mm² crimped or soldered)
Also suited for mounting into cover plate 2561-xxx, Protection class (Device): IP 20
2564-02-xxx and bases 1812, 1866 EB, and 1867 EB.
RJ-45 terminals for networks according to Cat 6A, Class 0299-0-0032 2CKA000299A0032 10
EA (10 Gbits/s / 500MHz).
Equates to cat. 6a, Class EA according to
ISO/IEC 11801:2011-06. Blank plate
Cat. 6A according to ISO/IEC 11801: 2011-06. with metal mounting plate
Terminal marking A and B according to TIA/EIA-568-B.2. Material stainless steel.
Typ according to EN 60 603-7-51:2011-01. Anti fingerprint.
Shielding according to DIN EN 55022, Class B. Protection class (Device): IP 20
Suitable for PoE+ according to IEEE 802.3at, >- 1.000
contact durability. stainless steel 1742-866 2CKA001710A3751 10
Bend-radius optimised cable feed (30°).
11
Earthing of housing via 6,3 mm blade terminal at the
back possible. Cover plate )
1
Re-embedded proofed. with metal mounting plate
Suitable for Mix-and-Match operation. As cover for flex outlet, for cords up to 10.3 mm
For 8-pole plug RJ 45 only. diameter.
Housing made from diecast zinc. With strain relief (without terminal block).
With integrated dust-protection cap (can be removed if Material stainless steel.
necessary). Anti fingerprint.
With insulation displacement connection Protection class (Device): IP 20
For data cables with a diameter of 6 -10 mm.
For wires of AWG 24-22. stainless steel 1749-866 2CKA001710A3752 10
For trunk systems, flush-mounted wall boxes and 1) Cover plate can also be used individually as cover for telephone connector boxes
underfloor systems. (VDo).
Protection class (Device): IP 20
0219-101 2CKA000230A0413 1/10 Cover plate )
1
As cover for universal data connection boxes.
1) With assembly adapters appropriate for telephone unit cover plates 2539-21x and
1766-xxx. Art.-No. 0213 (Cat 3/ISDN), 0216-101, 0218/11-101 (Cat
5e/6 data technology) and comparable types of the
company Rutenbeck.
Modular-Jack insert For WLAN access points 8186/31 and 8186/41.
6-pole Cat. 3 (AMP-No. 216000-2) Brand-Rex (WAEGV 8 EKR/EK).
For cover plate 2561-xxx, 2561-02-xxx and insert 1812, BTR ( universal data connecting unit design and IAE
1866 built-in, 1867 built-in. design).
For conductor cross-sections of 0.12 mm² (AWG 26) to Telegärtner (AMJ 45, UMJ 45).
0.35 mm² (AWG 22). With down-leading outlet.
Protection class (Device): IP 20 With labelling field.
0210 2CKA000225A0078 10 Size of labelling field: 60 x 9 mm.
Material stainless steel.
Anti fingerprint.
Modular-Jack insert Protection class (Device): IP 20
8-pole Cat. 3 (AMP-No. 216005-4) stainless steel 1803-866 2CKA001710A3763 10/100
For cover plate 2561-xxx, 2561-02-xxx and insert 1812,
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
1866 built-in, 1867 built-in.
For conductor cross-sections of 0.12 mm² (AWG 26) to
0.35 mm² (AWG 22).
Protection class (Device): IP 20
0211 2CKA000225A0086 10
