11/109

—
pure stainless steel
Socket outlets Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

SCHUKO® socket outlet WLAN access point, flush-mounted ) )
2
1
shuttered power supply from mains power
With screwless terminals. Operation as WLAN access point for the connection of
DP (2 P + E) WLAN terminal devices to the LAN.
with hinged lid Operation as WLAN repeater for extending the
Material stainless steel. transmission range of a WLAN.
Anti fingerprint. Operation as WLAN adapter for integrating Ethernet
Rated voltage: 250 V~ terminal devices into a WLAN.
Rated current: 16 A Supports WLAN standards IEEE 802.11b/g/n with
Protection class (Device): IP 20 2.4 GHz; integrated WLAN antenna.
Backward connection of an Ethernet cable via screw
stainless steel 20 EUKB-866 2CKA002018A1521 10/100
terminals (10/100 Mbit/s).
Front-side Ethernet connection via a RJ45 socket
Socket outlet ) ) (10/100 Mbit/s).
1
2
with earthing pin The three connections (WLAN, Ethernet/screw terminals
With screwless terminals. and Ethernet/RJ45)can be used in parallel via the
Shuttered. integrated switch.
Suitable for the countries like Poland, Czech Republic. Power supply via 2-pole connecting terminal.
DP (2 P + E) Nominal voltage: 100 - 240 V~
Rated voltage: 250 V~ For mounting in commercially available deep flush-
Rated current: 16 A mounted and hollow-wall boxes.
Rated frequency: 50 Hz - 60 Hz
stainless steel 20 MUCKS-866-500 2CKA002017A0900 10
Protection class (Device): IP 20
1) Socket outlet with integrated child protection. Replaces the usual term"...with child
protection". 8186/31-101-500 2CKA008100A0359 1
2) Order-bound manufacturing 1) Suitable for cover plate 1803-xxx.
2) Not to be mounted in SM box 1701-xxx, 1702-xxx, 1703-xxx. 11
Reset magnet
For resetting WLAN access point UP 8186/31-101 and
WLAN access point PoE UP 8186/41 to the factory
settings.
Protection class (Device): IP 20
8186/11-500 2CKA008100A0361 1

Universal data connection unit, cat. 3 )
1
1gang
With down-leading outlet.
For 8-pole plug, RJ 11/12, RJ 45, ISDN capability, Cat. 3.
Design according to IEC 60 603-7-2:2007.
Screw contacts
With claw.
Protection class (Device): IP 20
0213-500 2CKA000230A1549 10/100
1) Suitable for cover plate 1803-xxx.

Universal data connection box with down-leading
outlet )
1
2gang internally parallel connected
With down-leading outlet.
For 8-pole plug, RJ 11/12, RJ 45, ISDN capability, Cat. 3.
Design according to IEC 60 603-7-2:2007.
Screw contacts
With claw.
Protection class (Device): IP 20
0214 2CKA000230A0235 10/100
Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
neon indicator: not applicable
1) Suitable for cover plate 1803-02-xxx.
