11/240 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
future® linear
Blind control / timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Standard timer control element ) Comfort timer control element )
1
1
For manual and time-controlled switching of blinds and For manual and time-controlled switching of blinds,
roller blinds. roller blinds, awnings, lighting and other electrical
With dusk to dawn program including (Astro-program) devices.
Individual Astro adjustment and Astro blocking time. With dusk to dawn program including (Astro-program)
The controlled devices can be manually operated at any Individual Astro adjustment and Astro blocking time.
time. The controlled devices can be manually operated at any
Simple setting via high-resolution display with time.
background illumination. Simple setting via high-resolution display with
With preset switching times/date/time. background illumination.
Factory-set switching times can be individually With preset switching times/date/time.
adjusted. Factory-set switching times can be individually
Automatic switchover from summer time to winter time adjusted.
(switch-off function). Automatic switchover from summer time to winter time
Switching times/programme are safely stored in the (switch-off function).
event of a mains power failure. Switching times/programme are safely stored in the
Power reserve for time and date > 10 years. event of a mains power failure.
Simple toggling between manual/automatic/vacation Power reserve for time and date > 10 years.
modes. Simple toggling between manual/automatic/vacation
Programming possible only with control element modes.
attached and energized. Combined with Busch-Blind control II insert
2 switching times per day can be user-defined for each 6411 U/S-101, sun protection and twilight function.
day of the week. Freely adjustable temperature and brightness-
Astro switching times and switching times can be dependent sun protection function.
combined. Freely adjustable twilight function.
For basic blind insert 6418 U. User-adjustable running times for blinds and air
Temperature range (Device): 0 °C to 35 °C conditioning.
11
Programming possible only with control element
6456-101 2CKA006410A0398 1/10
attached and energized.
1) See respective cover plates 6435-xx.
6 switching times per day can be user-defined for each
day of the week.
Astro switching times and switching times can be
combined.
When combined with LED dimmer 6524 U, Busch-
Universal master dimmer insert 6593 U or Busch-
Memory touch-type controller 6550 U-101, the
brightness of the lighting can be adjusted for each ON
switching time.
For Busch-Blind control II insert 6411 U-101,
6411 U/S-101.
For Busch-Universal relay switch insert 6401 U-102.
For Busch-Universal master dimmer insert 6593 U.
For LED dimmer insert 6524 U and 6526 U..
For Busch-Memory touch-type controller 6550 U-101.
Temperature range (Device): 0 °C to 35 °C
6455-101-500 2CKA006410A0399 1/10
1) See respective cover plates 6435-xx.

Time switch mechanism 16 A ) )
1
2
DP, break contact for staircases, exterior lighting, fans,
etc.
Running time: 15 min
For time-programmed switching of electrical
consumers.
Rated voltage: 230 V~, +10 % / -10 %
Rated current: 16 A, cos φ 0.25
Protection class (Device): IP 20
1070 U 2CKA001043A0025 1/10
1) For screw-fixing only
2) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
