basic55®
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
Universal module, RJ 45, cat. 6a iso, shielded ) Mounting plate ) )
1
1
1gang with black insert
For installation in installation adapter 0219/12 or For MTRJ or 2 modular jack inserts.
0219/13. For systems: Ackermann, AMP / tyco Electronics (Slim
Also suited for mounting into cover plate 2561-xxx, Line (SL) -SM 2gang/switches: 110Connect Jacks,
2564-02-xxx and bases 1812, 1866 EB, and 1867 EB. Toolless Jacks / Standard 110Connect Jacks), Brand-Rex,
RJ-45 terminals for networks according to Cat 6A, Class CombiNet, EFB Electronic, Telena.
EA (10 Gbits/s / 500MHz). Equates to cat. 6a, Class EA For 2 fiber optic modules of the following types: AMP /
according to ISO/IEC 11801:2011-06. tyco Electronics MTRJ.
Cat. 6A according to ISO/IEC 11801: 2011-06. Pitch dimensions: (WxH) approx. 14.8 x 20.4 mm.
Terminal marking A and B according to TIA/EIA-568-B.2. Without claws.
Typ according to EN 60 603-7-51:2011-01. Protection class (Device): IP 20
Shielding according to DIN EN 55022, Class B. 1814-500 2CKA001753A9973 10/100
Suitable for PoE+ according to IEEE 802.3at, >- 1.000
contact durability. 1) Compatibility with other manufacturers not listed is to be checked in accordance
with specified snap-in dimensions.
Bend-radius optimised cable feed (30°). 2) For further information, please refer on the Internet.
Earthing of housing via 6,3 mm blade terminal at the
back possible.
Re-embedded proofed. Mounting plate ) )
2
1
Suitable for Mix-and-Match operation. with blue insert
For 8-pole plug RJ 45 only. For 2 modular jack inserts.
Housing made from diecast zinc. For system: ITT Cannon RJ45 Cat. 5 type 808 RJ45
With integrated dust-protection cap (can be removed if Mark III.
necessary). Pitch dimensions: (WxH) approx. 16.0 x 11.0 mm.
With insulation displacement connection Without claws.
For data cables with a diameter of 6 -10 mm. Protection class (Device): IP 20
For wires of AWG 24-22. 11
For trunk systems, flush-mounted wall boxes and 1816 2CKA001710A3100 10/100
underfloor systems. 1) Compatibility with other manufacturers not listed is to be checked in accordance
Protection class (Device): IP 20 with specified snap-in dimensions.
2) For further information, please refer on the Internet.
metal clad 0219-101-507 2CKA000230A0414 1/10
1) With assembly adapters appropriate for telephone unit cover plates 2539-21x and
1
2
1766-xxx. Mounting plate ) )
with orange base
For 2 modular jack inserts.
2
Mounting plate ) ) For system: LexCom 150 and LexCom 250.
1
with green insert Pitch dimensions: (WxH) approx. 15.4 x 15.4 mm.
For 2 modular jack inserts. Without claws.
For systems: CommScope (AVAYA / AT&T / Lucent Protection class (Device): IP 20
Technologies), GigaSPEED, PowerSUM, 360 GS 10E bis
MGS 600-BK, M1 BH-xx, MPS 100E-xx. 1819 2CKA001753A8056 10/100
With R&M adapter R310694 suitable for R&M connection 1) Compatibility with other manufacturers not listed is to be checked in accordance
modules R305111, R305112, R305113 and R305114. with specified snap-in dimensions.
2) For further information, please refer on the Internet.
Pitch dimensions: (WxH) approx. 16.9 x 17.9 mm.
Without claws. Protection class (Device): IP 20
1
2
1810-500 2CKA001753A9974 10/100 Mounting plate ) )
with grey base
1) Compatibility with other manufacturers not listed is to be checked in accordance
with specified snap-in dimensions. For 2 modular jack inserts.
2) For further information, please refer on the Internet. For system: Panduit MiniCom (Cu. z.B. TX6 10 Gig
Shielded Jack modules and fiber optic modules.
Pitch dimensions: (WxH) approx. 15.9 x 18.7 mm.
Mounting plate ) ) Without claws.
1
2
with red insert Protection class (Device): IP 20
For 2 modular jack inserts. 1820 2CKA001753A8057 10/100
Suitable for Art. Nos. 0210, 0211 and 0219-101.
For systems: AMP / tyco Electronics, BTR, EFB, Krone, 1) Compatibility with other manufacturers not listed is to be checked in accordance
with specified snap-in dimensions.
Panduit, Quante, Radiall, Setec, Dr.-Ing. Sieger, Telena, 2) For further information, please refer on the Internet.
Thomas & Betts
For Telegärtner AMJ/UMJ connection modules/
couplings. For 2 fiber optic modules of the following
types: 3M-Volition, Krone, mvk.
Pitch dimensions: (WxH) approx. 14.8 x 19.4 mm.
Without claws.
Protection class (Device): IP 20
1812-500 2CKA001753A9972 10/100
1) Compatibility with other manufacturers not listed is to be checked in accordance
with specified snap-in dimensions.
2) For further information, please refer on the Internet.
