11/342 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Sky Niessen - Free@home - Home automation
Wireless sensor & blind actuators Wireless temperature controller

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

free@home Sensor/Blind actuator - 1/1-gang - Wireless free@home Room thermostat - Wireless
Rated voltage: 230 Vac - 50/60Hz. Rated voltage: 230 Vac - 50/60Hz.
For controlling blind or awning motors. Heating/cooling operation.
Wireless communication with the free@home system. Wireless communication with the free@home system.
With integrated blind actuator. Blind function is available Control element with room temperature controller
also without prior programming (pre-configured). function. With display of set-value temperature. In
Configuration can be changed later via the web interface connection with temperature sensor 6226/T the
(groups, scenes, etc.). integrated room temperature controller can be fitted
3 wire connection (neutral conductor required). with a remote sensor.
With two 230 V extension unit inputs (Up/Down). With fixing claws.
With fixing claws. Control element: floating rocker for the selection of set
Control element: switch contacts top/bottom. values and operating modes.
Display elements: LED as light for orientation or display Display elements: LCD showing operation modes.
of the switching state. Temperature range device: -5 °C to 45 °C.
Outputs: 2 Normally Open contact, potential-bound Mounting depth: 32 mm.
(output voltage: 230 Vac). To be installed with CP-RTC-85 cover plates for RTC or
Suitable for: blind motors. CP-RTC-FC-85 for fan coil control.
Rated current / power: 4 A / 920 VA.
Temperature range device: -5 °C to 45 °C. RTC-F-1-WL 2CKA006200A0081 1
Mounting depth: 32 mm.
To be installed with SR-1-85 cover plates.
free@home Room thermostat/actuator - Wireless
Rated voltage: 230 Vac - 50/60Hz.
SBA-F-1.1.1-WL 2CKA006200A0079 1
Rated frequency: 50 Hz / 60 Hz.
Heating/cooling operation.
free@home Sensor/Blind actuator - 2/1-gang - Wireless Wireless communication with the free@home system.
Rated voltage: 230 Vac - 50/60Hz. Control element with room temperature controller
For controlling blind or awning motors. function. With display of set-value temperature. With
11
Wireless communication with the free@home system. integrated switch actuator, e.g. for controlling
With integrated blind actuator. Blind function is available thermoelectric actuating drives in heating/cooling
also without prior programming (pre-configured). systems or electric floor heating systems. RTC function is
Configuration can be changed later via the web interface available also without prior programming
(groups, scenes, etc.). The right sensor channel for (pre-configured). In connection with temperature sensor
programming additional functions (groups, scenes, etc.). 6226/T the integrated room temperature controller can
3 wire connection (neutral conductor required). be fitted with a remote sensor.
With two 230 V extension unit inputs (Up/Down). 3 wire connection (neutral conductor required).
With fixing claws. With fixing claws.
Control element: switch contacts top/bottom. Control element: floating rocker for the selection of set
Display elements: LED as light for orientation or display values and operating modes.
of the switching state. Display elements: LCD showing operation modes.
Outputs: 2 Normally Open contacts, potential-bound Outputs: 1 Normally Open contact, potential-bound
(output voltage: 230 Vac). (output voltage: 230 Vac).
Suitable for: blind motors. Suitable for: ohmic.
Rated current / power: 4 A / 920 VA. Rated current / power: 16 A / 3680 W.
Temperature range device: -5 °C to 45 °C. Temperature range device: -5 °C to 45 °C.
Mounting depth: 32 mm. Mounting depth: 32 mm.
To be installed with SR-2-85 cover plates. To be installed with CP-RTC-85 cover plates.
RTC-F-2.1.1-WL 2CKA006200A0082 1
SBA-F-2.1.1-WL 2CKA006200A0080 1
