11/384 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Impressivo
Signal

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Signal Push Button with Cord Stereo Plug Terminal
Signal Push Button with Cord corresponds technically Stereo Plug Terminal is used for 6.3 mm Jack connector
to the Signal Push Button FAP2001. Length of the white (stereo). It can be used in calling and alarm systems as
Cord is 2,5 meters and the red Cord in 8 meters. a socket outlet for connecting the Wire Push Button
FAP9001, or as a headphone or loudspeaker terminal.
Good marking possibilities.
Jussi, includes insert and center plate Jussi, includes insert and center plate
Signal Push Button with Cord Stereo Plug Terminal for 6,3mm Jack Plug
FAP3002 2TKA002098G1 1/10 FOT3103 2TKA002180G1 1/10
FAP3002.PU 2TKA00003391 1/10
Impressivo, center plate
Impressivo, center plate Center plate, Telecom socket outlet
Center plate, 2-fold white T-84 2TKA003321G1 1/10
white 2P-84 2TKA000893G1 1/10 Center plate, Telecom socket outlet
Center plate, 2-fold anthracite T-81 2TKA003319G1 1/10
anthracite 2P-81 2TKA000891G1 1/10 Center plate, Telecom socket outlet
Center plate, 2-fold aluminium T-83 2TKA003320G1 1/10
aluminium 2P-83 2TKA000892G1 1/10
Wire Push Button
Signal Push Button with Stereo Plug Terminal Push Button with 6.3 mm Jack plug (stereo). Closing
Signal Push Button with LED. Additional plug for contact. Lenght 2m.
6.3 mm Jack connector (FAP9001). Adressed /
non-adressed function. Good marking possibilities.
Operating voltage: 9,5-28 Vac / 9,5-35 Vdc. Current
11
consumption: 20 mA ac / 10 mA dc. Switching voltage / Wire Push Button with 6,3mm Jack Plug
-current / -power: 30 Vac/35 Vdc / 100 mA ac/dc / FAP9001 2TKA002105G1 1/10
3 VA/W.
Jussi, includes insert and center plate
Button / Buzzer
Signal Push Button with Stereo Plug Terminal A device including a push button as well as a buzzer.
FAP3011 2TKA002103G1 1/10 The LED of the push button and the buzzer operates in
parallel. The buzzer can be cancelled with the push
Impressivo, center plate button. In alarm position the LED flickers. When
Center plate, Push button/telecom socket outlet cancelled it lits constantly till the alarm goes off. Good
white PT-84 2TKA003208G1 1/10 marking possibilities on the push button and the name
plate. Operating voltage 9,5 - 28 Vac / 9,5 - 35 Vdc.
Center plate, Push button/telecom socket outlet Current consumption: 45 mA ac / 35 mA dc. Load
anthracite PT-81 2TKA003206G1 1/10 capacity of the switch: 42 Vac / 60 Vdc, 250 mA ac/dc,
6 VA / 4 W.
Center plate, Push button/telecom socket outlet
aluminium PT-83 2TKA003207G1 1/10 Jussi, includes insert and center plate
Button / Buzzer
FIP1001 2TKA002144G1 1/10
Impressivo, center plate
Center plate, 1-fold
white 1P-84 2TKA000632G1 1/10
Center plate, 1-fold
anthracite 1P-81 2TKA000630G1 1/10
Center plate, 1-fold
aluminium 1P-83 2TKA000631G1 1/10

IMPRESSIVO CENTER PL ATES FOR JUSSI SIGNALLING PRODUCTS.
INCLUDES THE NEEDED PARTS TO MODIF Y THE JUSSI SIGNALLING PRODUCT TO IMPRESSIVO.
