Impressivo
Signal

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Transformer Alarm Unit, 1-loop
Small size transformer to be installed in normal Operates as FEH1001, but has a bigger signal light,
mounting box. Short circuit protected. which flashes during alarm. When cancelled, it lits
Voltage: 230 V ac / 15 V ac. constantly. Cancelling/disconnection has its own input.
Power / loading capacity: 2,2 VA / 150 mA. When a push button/switch is connected to this
terminal, the device could be cancelled/disconnected
from a distance or from several points. Possibility to
Jussi, includes insert and center plate
connect closing and opening potential free contacts.
Transformer Loop controls itself against short circuits and breaks.
FLM1000 2TKA002168G1 1/10 Function selector "M" memory ON/OFF. Potential free
output. Operating voltage: 15 - 28 V ac / 18 - 35 V dc.
Impressivo, center plate Current consumption 110 mA ac / 60 mA dc. Sound
Center plate, blind intensity/frequency: 78 dB / 2,3 kHz / 30cm.
white U-84 2TKA003414G1 1/10 Jussi, includes insert and center plate
Center plate, blind Alarm Unit, 1-loop
anthracite U-81 2TKA003412G1 1/10 FEH2001 2TKA002112G1 1/10
Center plate, blind
aluminium U-83 2TKA003413G1 1/10 Impressivo, center plate
Center plate, Signal light
white V-84 2TKA003461G1 1/10
Control Units, 1- and 2-loop
Available as 1- or 2-loop. Each loop has a LED and Center plate, Signal light
a cancelling/disconnecting button. The LED flashes anthracite V-81 2TKA003459G1 1/10
during alarm. When cancelled/disconnected the LED Center plate, Signal light
lits constantly. Possibility to connect closing and aluminium V-83 2TKA003460G1 1/10 11
opening potential free contacts. Loop controls itself
against short circuits and breaks. Function selectors
"M" memory ON/OFF and "T" delay 150ms/2,5 sec. Signal Push Button
Potential free output. Good marking possibilities. Signal Push Button with LED. Adressed / non-adressed
Operating voltage: 15 - 28 V ac / 18 - 35 V dc. function. Good marking possibilities.
Current consumption, FEH1001 and FEH1101: Operating voltage 9,5 - 28 V ac / 9,5 - 35 V dc.
70 mA ac / 40 mA dc, FEH 1002: 110 mA ac / 60 mA dc. Current consumption: 20 mA ac / 10 mA dc.
Switching voltage / -current / -power: 30 V ac /
Jussi, includes insert and center plate
35 V dc / 100 mA ac/dc / 3 VA/W.
Control Unit, 1-loop
FEH1001 2TKA002107G1 1/10 Jussi, includes insert and center plate
Signal Push Button, 1-fold
Control Unit, 2-loop FAP2001 2TKA002095G1 1/10
FEH1002 2TKA002110G1 1/10
Control Unit, 1-loop, disconnectable Impressivo, center plate
FEH1101 2TKA002111G1 1/10 Center plate, 1-fold
white 1P-84 2TKA000632G1 1/10
Impressivo, center plate
Center plate, 1-fold
Center plate, 1-fold
white 1P-84 2TKA000632G1 1/10 anthracite 1P-81 2TKA000630G1 1/10
Center plate, 1-fold
Center plate, 1-fold
anthracite 1P-81 2TKA000630G1 1/10 aluminium 1P-83 2TKA000631G1 1/10
Center plate, 1-fold
aluminium 1P-83 2TKA000631G1 1/10
Center plate, 2-fold
white 2P-84 2TKA000893G1 1/10
Center plate, 2-fold
anthracite 2P-81 2TKA000891G1 1/10
Center plate, 2-fold
aluminium 2P-83 2TKA000892G1 1/10

IMPRESSIVO CENTER PL ATES FOR JUSSI SIGNALLING PRODUCTS.
INCLUDES THE NEEDED PARTS TO MODIF Y THE JUSSI SIGNALLING PRODUCT TO IMPRESSIVO.
