Impressivo
Signalling Devices

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Signal Lights Alarm Unit
Device with LED signal light. Opal lense. Alarm Unit with flashing LED light and interrupting
Operating voltage of LED's: 9,5 - 28 V ac / 9,5 - 35 V dc. sound. Operating voltage: 9,5 - 28 V ac / 9,5 - 35 V dc.
Current consumption: 60 mA ac / 30 mA dc. current consumption: 60 mA ac / 30 mA dc. Sound
intensity / frequency: 78 dB / 2,3 kHz (intensity
measured at 30 cm distance). Sound disconnectable.
Jussi, includes insert and center plate Jussi, includes insert and center plate
Signal Light Alarm Unit
red FIM1000 2TKA002120G1 1/10 yellow FIM1210 2TKA002135G1 1/10
Signal Light Alarm Unit
yellow FIM1010 2TKA002123G1 1/10 red FIM1200 2TKA002131G1 1/10
Signal Light
green FIM1020 2TKA002125G1 1/10 Impressivo, center plate
Center plate, Signal light
Signal Light
white FIM1030 2TKA002127G1 1/10 white V-84 2TKA003461G1 1/10
Center plate, Signal light
Impressivo, center plate anthracite V-81 2TKA003459G1 1/10
Center plate, Signal light Center plate, Signal light
white V-84 2TKA003461G1 1/10 aluminium V-83 2TKA003460G1 1/10
Center plate, Signal light
anthracite V-81 2TKA003459G1 1/10 Signal Panel
Center plate, Signal light Could be used as an 3/6 points alarm receiving panel in
aluminium V-83 2TKA003460G1 1/10 calling and alarm systems. With 6 red LED's. 11
Good marking possibilities.
Operating voltage: 12 - 24 V ac/dc.
Buzzer
Two audio frequencies available. Volume adjustment
possible. Operating voltage: 9,5 - 28 V ac / 9,5 - 35 V dc. Jussi, includes insert and center plate
Current consumption: 40 mA ac / 20 mA dc. Sound Signal Panel
intensity / frequency: 70 dB / 250 Hz or 70 dB / 750 Hz FIM1300 2TKA002136G1 1/10
(intensity measured at 30 cm distance). Full sound
intensity when operating voltage at least 15V ac or Impressivo, center plate
18V dc. Center plate, signal panel
Jussi, includes insert and center plate white 6V-84 2TKA001578G1 1/10
Buzzer Center plate, signal panel
FIM1100 2TKA002128G1 1/10 anthracite 6V-81 2TKA001576G1 1/10
Center plate, signal panel
Impressivo, center plate
aluminium 6V-83 2TKA001577G1 1/10
Center plate, blind
white U-84 2TKA003414G1 1/10
Disabled WC set, Impressivo
Center plate, blind Impressivo disabled WC SET contains the following
anthracite U-81 2TKA003412G1 1/10 signalling products: 1 pc Transformer, 1 pc 1-loop
Center plate, blind Alarm Unit, 1 pc Signal Push Button with Draw Cord
aluminium U-83 2TKA003413G1 1/10 (calling) and 1 pc Signal Push Button (cancelling). All
devices are equipped with Impressivo coverframes.
Impressivo Disabled WC, set
FJW1004-84 2TKA00001119 1/10

IMPRESSIVO CENTER PL ATES FOR JUSSI SIGNALLING PRODUCTS.
INCLUDES THE NEEDED PARTS TO MODIF Y THE JUSSI SIGNALLING PRODUCT TO IMPRESSIVO.
