Impressivo
Signalling Devices Office Signal

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Jussi Leak Guard Impressivo, Door Panel
The Leak Guard unit operates as the standard Control The Door Panel can be installed either surface or
Unit FEH1001, with the exception that the loop flush-mounted on top of a 1- or 2-gang mounting box.
monitors leakage current (10 µA). Tape sensors, conduit Compatible with Table Panel FIP2000-8x.
pairs or other leakage sensors could be connected to Operating voltage: 15 - 28 V ac.
the device. Memory/no memory function. Potential free Current consumption: 75 mA (max).
output. Cancelling button with LED.
Operating voltage: 9,5 - 28 V ac / 9,5 - 35 V dc. Door Panel for office signal system
Current consumption: 75 mA ac / 40 mA dc. Good white FIO2000-84 2TKA002142G1 1/10
marking possibilities on the button and name plate.
Jussi, includes insert and center plate Impressivo Table Panel
The Table Panel can be used for controlling the signal
Leak Guard lights of Door Panel FIO2000-xx. It also includes a freely
FEH2100 2TKA002115G1 1/10 adaptable Push Button and Switch, which can be
integrated into an existing emergency or assistant call
Impressivo, center plate
system using the Adapter Relay FIR2000. 2 meters
Center plate, 1-fold connecting wire. Operating voltage: 15 - 28 V ac.
white 1P-84 2TKA000632G1 1/10
Table Panel for office signal system
Center plate, 1-fold white FIP2000-84 2TKA002148G1 1/10
anthracite 1P-81 2TKA000630G1 1/10
Center plate, 1-fold Table Panel Terminal
aluminium 1P-83 2TKA000631G1 1/10 Table Panel is connected to a RJ12 terminal. The yellow
light could be controlled automatically. FOR2000 could
be used in both analog and digital telephone systems.
Mains Relay
With mains relay Jussi leak guard can control 230 V ac FOT2000 is used in digital telephone systems or when
11
magnetic valves.. Controlled by low voltage potential the automatic control of the yellow light is not used.
free contact (e.g. switches, push buttons, potential free Jussi, includes insert and center plate
contacts or alarm panels). Separate transformer not Table Panel Terminal
needed. Loading capacity: 10 A / 230 V ac. Fluorescent
light load max 300 VA. FOT2000 2TKA002177G1 1/10
Jussi, includes insert and center plate Impressivo, center plate
Mains Relay Center plate, 2 x RJ45, dust covers
FIR1000 2TKA002152G1 1/10 white 1819DC-84 2TKA00001111 1/10
Impressivo, center plate
Adapter Relay
Center plate, blind The Adapter Relay is used to integrate the Office Signal
white U-84 2TKA003414G1 1/10 System with calling- or alarm systems. Operating
Center plate, blind voltage 15 - 28 V ac.
anthracite U-81 2TKA003412G1 1/10
Center plate, blind
aluminium U-83 2TKA003413G1 1/10 Jussi, includes insert and center plate
Adapter Relay
FIR2000 2TKA002155G1 1/10
Tape Sensors
Self adhesive Leak Guard sensor. Wires connected to Impressivo, center plate
sensor by soldering.
Center plate, blind
white U-84 2TKA003414G1 1/10
Center plate, blind
Tape Sensor, lenght 2 m anthracite U-81 2TKA003412G1 1/10
FLA2100.02 2TKA002164G1 1/10 Center plate, blind
Tape sensor, lenght 50 m aluminium U-83 2TKA003413G1 1/10
FLA2100.50 2TKA002166G1 1

IMPRESSIVO CENTER PL ATES FOR JUSSI SIGNALLING PRODUCTS.
INCLUDES THE NEEDED PARTS TO MODIF Y THE JUSSI SIGNALLING PRODUCT TO IMPRESSIVO.
