11/388 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Impressivo
Accessories

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Claws Adapter 85/100mm, IP21/IP44
Claws for 1-gang socket outlets, Euro socket outlets, 1-gang center plated accessories can be mounted in
switches and push switches. Not suitable for 2-gang 100mm cover frames with the adapter. Final IP class of
Impressivo socket outlet inserts. Inserts with claws are installation is defined by the accessories.
also available.

Claws for socket outlets and swithces white 2519-84 2TKA000808G1 1/20
ASE1 2TKA001721G1 10/100 anthracite 2519-81 2TKA000804G1 1/20
aluminium 2519-83 2TKA000806G1 1/20
Screw-mounted rocker frames, IP44
Screw-mounted rocker frame is used with the seals
2463 or 2464 to reach IP44 protection class on Labeling plate
switches and push switches. Furthermore, it can be Labeling plate for cover frames.
used to connect the switch frame to the insert with Size of text area is max 12 x 52 mm.
screws for improved security.
Modular
Supporting frame for 1/3-gang rocker, screw fastening 2752 2TKA00000053 10/100
2474 2TKA000004G1 20/200
Supporting frame for 2-gang rocker, screw fastening Impulse spring
2475 2TKA000005G1 20/200 Impulse spring for ABB switches, 10 pcs in sales pack

Seal 85mm for 1-gang socket outlet, IP44
1-gang socket outlet inserts installed with the seal and
11
a center plate with hinged lid are IP44. Switches and
push buttons installed with the seal and with the PJ4.10 2TKA00003056 10/100
screwmounted rocker frames are IP44.
2463 2TKA000002G1 20/200

Seal 100mm for 2-gang socket outlet, IP44
2-gang socket outlet inserts installed with the seal and
a center plate with hinged lids are IP44. Switches, push
buttons and 1-gang socket outlets with a hinged lid are
also IP44, when using the seal with adaptor 2519-xx.
Screw mounted rocker frame must be used to reach
IP44 protection class.
2464 2TKA000003G1 20/200

Blind center plate, 85mm
85mm blind center plate can be used to cover an empty
box. It can be used together with 85mm flush- and
surface mounting frames. Flush mounting: On a smooth
surface IP21, on a rough surface IP20 (seal can't be
used). When installed on surface with 2456.26 and
172xS85-xx, protection class is IP44.
white 2538-84 2TKA000856G1 1/10
anthracite 2538-81 2TKA000852G1 1/10
aluminium 2538-83 2TKA000854G1 1/10

Blind center plate, 100mm
100mm blind center plate can be used to cover an
empty box. Can be used together with 100mm flush-
and surface mounting frames. Flush mounting: On a
smooth surface IP21, on a rough surface IP20 (seal can't
be used). When istalled on surface the protection class
is IP44 if wires are installed downwards.
white 2538-100-84 2TKA000848G1 1/10
anthracite 2538-100-81 2TKA000846G1 1/10
aluminium 2538-100-83 2TKA000847G1 1/10
