11/380 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Impressivo
Multimedia Thermostats

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

DigitalRadio set Floor heating thermostat
2-gang combination digital radio and loudspeaker Floor heating thermostat for room-specific
(flush mounted). The radio offers a stereo RDS tuner temperature adjustment. 230 V~, 50 Hz, 15 A / 3450 W,
with 8 memory presets as well as programmable clock, IP 31. Sensor: 3 m NTC 15 kΩ / 25 °C. Operating
alarm and snooze functions which are controlled with temperature: -10…+30 °C. Switch: 2-pole. Screw
the switch rocker. terminals: max. 2x2.5 mm2. Temperature drop: fixed 5
°C. Adjustment range: +5…+ 45 °C. Hysteresis +/- 0,4 °C.
white 8220-84 2TKA001587G1 1/10
Ball pressure temperature: 75 °C. Utilization category:
2 (home use). Type: 1C. Method of mounting: fixed.
DigitalRadio Includes insert and center plate
The radio offers a stereo RDS tuner with 8 memory
presets as well as programmable clock, alarm and Floor heating thermostat, 16 A, with sensor
snooze functions. Output max. 2x2W. Frequency white TF16-15-84 2TKA00002923 1/10
response: 100-10 000 Hz. Reception frequency
87,50-108,0 Mhz. IP20. Sold in parts
Insert Floor heating thermostat, 16 A, with sensor, Insert
TF16-15U 2TKA00002848 1/10
Digital Radio Insert, FM
8215U 2TKA001586G1 1/10 Center plate, for thermostat
white T-11-84 2TKA00000274 1/10
Center plate Center plate, for thermostat
white 8252-84 2TKA001592G1 1/10 anthracite T-11-81 2TKA00000267 1/10
anthracite 8252-81 2TKA001590G1 1/10 Center plate, for thermostat
aluminium 8252-83 2TKA001591G1 1/10 aluminium T-11-83 2TKA00000273 1/10
11
Loudspeaker Combination thermostat 15A
For DigitalRadio 8215U. Size 2". Rated output 2W. Combination thermostat can be used as a combination
Frequency response: 200-20 000 Hz, IP20. thermostat or only either as a room thermostat or floor
heating thermostat.
Set the room temperature to the desired value with the
round adjustment knob; the adjustment range is
+5...+35 °C
Insert Set the maximum floor temperature by turning the
Loudspeaker insert adjustment screw in the top left corner; the adjustment
8223U 2TKA001588G1 1/10 range is +20...+50 °C.
When the thermostat is used to adjust a floor heating
Center plate element heating a floor made of wood or corresponding
material, never set the maximum floor temperature to
white 8253-84 2TKA001597G1 1/10
over +35 °C (factory setting), or according to the floor
anthracite 8253-81 2TKA001595G1 1/10 material manufacturer’s instructions.
aluminium 8253-83 2TKA001596G1 1/10 The device measures the temperature inside the floor,
which differs from the floor’s surface temperature.
Freezing protection: Set the adjustment knob to
iNetRadio position 5, and the thermostat will keep room
WLAN Internet radio with display for flush-mounted temperature at +5 °C.
installation. For the reception of national and Temperature limiting: There are limiting pins under the
international radio stations via Internet. Radio station adjustment knobs that use to limit the movement of
search possible via various genres. Integrated the adjustment knob. Move the pins to the desired
web-server for configuration and control. Remote position to set the maximum and minimum
operation with smartphone via browser surface. UPnP temperatures. 230V~ / 50Hz / 15A / 3450W / IP 31 /
replay function. It is controlled via smartphone. doubleinsulated / sensor: 3 m / NTC 15 kΩ / 25 °C /
For mono/stereo operation. 8 radio stations storable. Operating temperature: -10…+30 °C / switch: 2-pole /
screw terminals: max. 2x2.5 mm2/ temperature drop:
Set *
fixed 5 °C / adjustment range: +5…+ 45 °C / hysteresis
iNetRadio kit +/- 0.4 °C.
8240-84-500 2TKA00002109 1/10
Includes insert and center plate
Center plate * white TC-15-13-84 2TKA00002055 1/10
iNetRadio anthracite TC-15-13-81 2TKA00002056 1/10
8216U-500 2TKA00002110 1/10 aluminium TC-15-13-83 2TKA00002057 1/10
DigitalRadio, center plate
white 8252-84 2TKA001592G1 1/10
DigitalRadio, center plate
anthracite 8252-81 2TKA001590G1 1/10
DigitalRadio, center plate
aluminium 8252-83 2TKA001591G1 1/10
* Delivery time to ask.
