Impressivo – surface mounting
Cover frames

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Surface mounting cover frames 85mm, IP21/IP44 Surface mounting cover frames 100mm, IP21/IP44
1-gang 1-gang
Surface mounting cover frames for 1-gang devices, Surface mounting cover frames for 2-gang devices,
such as switches and socket outlets. Suitable for both such as double socket outlets. Also 1-gang devices can
horizontal and vertical installation. To be used with be installed using the adaptor 2519-xx. Suitable for
surface mounting box 2456.26. Dimmers do not fit in both horizontal and vertical installation. To be used
the frame. Wires must be installed downwards for IP44 with surface mounting box 2456.26. Wires must be
protection class. Final IP class of installation is defined installed downwards for IP44 protection class. Final
by the used center plate (IP21/IP44). IP class of installation is defined by the used center
h=40mm plate (IP21/IP44).
h=40mm
white 1721S85-84 2TKA000302G1 1/50
anthracite 1721S85-81 2TKA000298G1 1/50 white 1721S100-84 2TKA000295G1 1/50
aluminium 1721S85-83 2TKA000300G1 1/50 anthracite 1721S100-81 2TKA000291G1 1/50
aluminium 1721S100-83 2TKA000293G1 1/50
Surface mounting cover frames 85mm, IP21/IP44
2-gang Surface mounting cover frames 100mm, IP21/IP44
2-gang

white 1722S85-84 2TKA000347G1 1/25
anthracite 1722S85-81 2TKA000344G1 1/25 white 1722S100-84 2TKA000342G1 1/25
anthracite 1722S100-81 2TKA000340G1 1/25
aluminium 1722S85-83 2TKA000345G1 1/25
aluminium 1722S100-83 2TKA000341G1 1/25
11
Surface mounting cover frames 85mm, IP21/IP44
3-gang Surface mounting cover frames 100mm, IP21/IP44
3-gang

white 1723S85-84 2TKA000385G1 1/25
anthracite 1723S85-81 2TKA000383G1 1/25 white 1723S100-84 2TKA000381G1 1/25
anthracite 1723S100-81 2TKA000379G1 1/25
aluminium 1723S85-83 2TKA000384G1 1/25
aluminium 1723S100-83 2TKA000380G1 1/25
Surface mounting cover frames 85mm, IP21/IP44
4-gang Surface mounting cover frames 100mm, IP21/IP44
4-gang

white 1724S85-84 2TKA000417G1 1/25
anthracite 1724S85-81 2TKA000415G1 1/25 white 1724S100-84 2TKA000413G1 1/20
aluminium 1724S85-83 2TKA000416G1 1/25 anthracite 1724S100-81 2TKA000411G1 1/20
aluminium 1724S100-83 2TKA000412G1 1/20
