11/393

—
Impressivo
KNX

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Bus Coupler IR remote control
For connecting operating elements such as a push Infrared hand-held transmitter. Network-independent
buttons (1-, 2-, 4-fold), motion detectors, room remote control for infrared receiver and KNX
thermostats etc. to the ABB i-bus® KNX system. flushmounted infrared interface (10 consumers
switchable in 2 groups, 1 – 5/6 – 10, programming and
selection of 2 MEMO memories per address group).
Supply: 4 alkaline manganese batteries, IEC LR03
6120/12-101-500 2TKA00000219 1/10
(not included in scope of supply) Range: frontal,
approx. 15 m.
Switch sensor, 1/2-gang 6010-25 2TKA001017G1 1
Flush mounted multifunction push button for ABB i-bus
KNX 6120/12-101-500. With labelling field, transparent
labelling sheet with standard symbols included in Control element, 2/4gang,
delivery. Support of KNX functions through innovative with RTC multi-function/colour concept
colour concept yellow=lighting, blue=blind, For ABB i-bus® KNX bus coupler 6120/12-101-500,
orange=RTC, magenta=scene and white=neutral/no 6120/13-500. Support of KNX functions through
function assigned) or standard illumination red/green. innovative colour concept (yellow = lighting,
Cover plate not included. blue = blind, orange = RTC, magenta = scene and
white = neutral/no function assigned) or standard
white 6125/02-84-500 2TKA00000271 1/10
illumination red/green.
anthracite 6125/02-81-500 2TKA00000266 1/10 Rocker switch left/right (switching/dimming/blind/
aluminium 6125/02-83-500 2TKA00000269 1/10 value sender/light scenes/fan function). Master/slave
configuration. With base-load operation. The controller
is a constant room temperature controller for ventilator
Switch sensor, 2/4-gang convectors (fan coils) in 2-pipe and 4-pipe systems and
Flush mounted multifunction push button for ABB i-bus conventional heating or cooling systems. The fan stage 11
KNX 6120/12-101-500. With labelling field, transparent can be switched manually or in auto- matic mode.
labelling sheet with standard symbols included in Transparent labelling sheet with standard symbols
delivery. Support of KNX functions through innovative included in delivery. Incl. 10 logic channels (light scene
colour concept yellow=lighting, blue=blind, actuator, sequence actuator, logic gates, etc.). Control
orange=RTC, magenta=scene and white=neutral/no element: Switch contacts left/right, also for selecting
function assigned) or standard illumination red/green. setpoint and mode of operation. Display elements: LCD
Cover plate not included. showing operation mode and temperature. Protection
class (Device): IP20. Temperature range (Device): -5 °C
white 6126/02-84-500 2TKA00000311 1/10
to 45 °C. Dimensions: (L x W x D): 63 mm x 63 mm.
anthracite 6126/02-81-500 2TKA00000297 1/10
grey metallic 6128/28-803-500 2TKA00003208 1/10
aluminium 6126/02-83-500 2TKA00000239 1/10
white 6128/28-84-500 2TKA00003206 1/10
anthracite 6128/28-81-500 2TKA00003204 1/10
Switch sensor, 4/8-gang
Flush mounted multifunction push button for ABB i-bus aluminium 6128/28-83-500 2TKA00003205 1/10
KNX 6120/12-101-500. With labelling field, transparent
labelling sheet with standard symbols included in Movement detector, with manual operation
delivery. Support of KNX functions through innovative Flush mounted sensor with Comfort II multi-lens. For
colour concept yellow=lighting, blue=blind, ABB i-bus KNX 6120/12-101-500. Movement detector
orange=RTC, magenta=scene and white=neutral/no with up to 4 channels. Incl. 10 logic channels (light
function assigned) or standard illumination red/green. scene actuator, sequence actuator, logic gates, etc.)
Cover plate not included.
Cover plate not included.
white 6127/02-84-500 2TKA00000327 1/10
white 6122/02-84-500 2TKA00000233 1/10
anthracite 6127/02-81-500 2TKA00000323 1/10
anthracite 6122/02-81-500 2TKA00000229 1/10
aluminium 6127/02-83-500 2TKA00000325 1/10
aluminium 6122/02-83-500 2TKA00000231 1/10
Switch sensor, 3/6-gang with IR-receiver
Flush mounted multifunction push button with
IR-receiver for ABB i-bus KNX 6120/12-101-500. With
labelling field, transparent labelling sheet with
standard symbols included in delivery. Support of KNX
functions through innovative colour concept
yellow=lighting, blue=blind, orange=RTC,
magenta=scene and white=neutral/no function
assigned) or standard illumination red/green.
Cover plate not included. Controlling with the
IR remote control 6010-25.
white 6129/01-84-500 2TKA00000246 1/10
anthracite 6129/01-81-500 2TKA00000242 1/10
aluminium 6129/01-83-500 2TKA00000244 1/10
