11/390 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Impressivo – surface mounting
Switches and push switches IP21 Socket outlets IP21

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1-gang switches 4-gang Schuko socket outlet, IP21
Switch with screwless terminals and lamp possibility. The device is based on two 2-gang socket outlet
Rocker with clip-on fastening. IP21 when wires are inserts, which are internally connected. The socket
installed downwards. outlet inserts have shutters. There are screwless
16AX/250V, 2 X-terminals terminals for each contact of the socket outlet insert
for max 4 rigid wires. No X-terminals. IP21 when the
wires are installed downwards.
1-gang 2-way switch
white 1066A-84 2TKA00001601 1/10 white 404EA-84 2TKA00001613 1/20
anthracite 1066A-81 2TKA00001602 1/10 anthracite 404EA-81 2TKA00001614 1/20
aluminium 1066A-83 2TKA00001603 1/10 aluminium 404EA-83 2TKA00001615 1/20

1-gang intermediate switch
2-gang Schuko socket outlet, IP21
white 1067A-84 2TKA00001846 1/10 Screwless terminals for each contact of the socket
anthracite 1067A-81 2TKA00001847 1/10 outlet for max 4 rigid wires. No X-terminals. The socket
outlet insert has shutters. IP21 when the wires are
aluminium 1067A-83 2TKA00001848 1/10 installed downwards.
2-gang switches white 402EA-84 2TKA00001607 1/10
Switch with screwless terminals, no lamp possibility. anthracite 402EA-81 2TKA00001608 1/10
Rocker with clip-on fastening. IP21 when wires are
installed downwards. aluminium 402EA-83 2TKA00001609 1/10
16AX/250V, 2 X-terminals
2-gang Schuko socket outlet, surface mounting, IP44
2-gang 1-way switch Product includes Schuko socket outlet insert, center
11
white 1065A-84 2TKA00001598 1/10 plate with lid, surface mountig cover frame and box.
The socket outlet insert has shutters and screwless
anthracite 1065A-81 2TKA00001599 1/10 terminals, branching terminals.
aluminium 1065A-83 2TKA00001600 1/10
anthracite 302ESW-81 2TKA00001754 1/10
2-gang 2-way switch
white 10666A-84 2TKA00001843 1/10
2-gang Schuko outlets with special colour, IP21
anthracite 10666A-81 2TKA00001844 1/10
Screwless terminals for each contact of the socket
aluminium 10666A-83 2TKA00001845 1/10 outlet for max 4 rigid wires. No X-terminals. The socket
outlet insert has shutters. IP21 when the wires are
installed downwards. These socket outlets can be used,
3-gang switch for instance, in hospitals and offices, when there is a
Switch with screwless terminals, no lamp possibility. need to limit socket outlet use to certain applications.
Rocker with clip-on fastening. IP21 when wires are
installed downwards. red 402EA-02 2TKA00002966 1/10
16AX/250V, 2 X-terminals orange 402EA-03 2TKA00002967 1/10
green 402EA-05 2TKA00002968 1/10
white 10631A-84 2TKA00001849 1/10
blue 402EA-06 2TKA00002969 1/10
anthracite 10631A-81 2TKA00001850 1/10
aluminium 10631A-83 2TKA00001851 1/10
2-gang Schuko socket outlet, lath installation, IP21
Schuko 2-gang socket outlet for lath installation. There
2-pole switch are screwless terminals for each contact of the socket
Switch with screwless terminals and lamp possibility. outlet for max 4 rigid wires. No X-terminals. The socket
Rocker with clip-on fastening. IP21 when wires are outlet insert has shutters.
installed downwards.
16AX/250V, 2 X-terminals white 402EL-84 2TKA00002273 1/10
anthracite 402EL-81 2TKA00002274 1/10
white 1062A-84 2TKA00001840 1/10
aluminium 402EL-83 2TKA00002275 1/10
1-gang push switch
Push switch with screwless terminals and lamp 2-gang Schuko socket outlet, corner installation, IP21
possibility. Rocker with clip-on fastening. Delivered Schuko 2-gang socket outlet for corner installation.
with clear lens. IP21 when the wires are installed There are screwless terminals for each contact of the
downwards. socket outlet for max 4 rigid wires. No X-terminals.
10A/250V, 2 X-terminals The socket outlet insert has shutters.
white 1461A-84 2TKA00001604 1/10
white 402EE-84 2TKA00001610 1/20
anthracite 1461A-81 2TKA00001605 1/10
anthracite 402EE-81 2TKA00001611 1/20
aluminium 1461A-83 2TKA00001606 1/10
aluminium 402EE-83 2TKA00001612 1/20
