11/426 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Zenit
Switches with indicator light

Color Article-No. Order-No. Pack/Qty Color Article-No. Order-No. Pack/Qty

Switch 1-gang, 1-way, SP - 1 M Push-button, SP without symbol - 1M
Rated voltage: 110 - 250 Vac. Rated voltage: 110 - 250 Vac.
Rated current: 16AX. Rated current: 16A.
Screwless terminals. Screwless terminals.
3 wires (Neutral conductor required). 3 wires (Neutral conductor required).
Included: indicator LED lamp N2192 RJ (230 Vac). Included: indicator LED lamp N2192 RJ (230 Vac).

White N2101.5 BL 2CLA210150N1101 5 White N2104.5 BL 2CLA210450N1101 5
Silver N2101.5 PL 2CLA210150N1301 5 Silver N2104.5 PL 2CLA210450N1301 5
Anthracite N2101.5 AN 2CLA210150N1801 5 Anthracite N2104.5 AN 2CLA210450N1801 5
Champagne N2101.5 CV 2CLA210150N1901 5 Champagne N2104.5 CV 2CLA210450N1901 5

Switch 1-gang, 1-way, SP - 2 M Push-button, SP without symbol - 2M
Rated voltage: 110 - 250 Vac. Rated voltage: 110 - 250 Vac.
Rated current: 16AX. Rated current: 16A.
Screwless terminals. Screwless terminals.
3 wires (Neutral conductor required). 3 wires (Neutral conductor required).
Included: indicator LED lamp N2192 RJ (230 Vac). Included: indicator LED lamp N2192 RJ (230 Vac).

White N2201.5 BL 2CLA220150N1101 5 White N2204.5 BL 2CLA220450N1101 5
Silver N2201.5 PL 2CLA220150N1301 5 Silver N2204.5 PL 2CLA220450N1301 5
Anthracite N2201.5 AN 2CLA220150N1801 5 Anthracite N2204.5 AN 2CLA220450N1801 5
Champagne N2201.5 CV 2CLA220150N1901 5 Champagne N2204.5 CV 2CLA220450N1901 5
11
Switch 1-gang, 2-way, SP - 1 M
Rated voltage: 110 - 250 Vac.
Rated current: 16AX.
Screwless terminals.
4 wires (Neutral conductor required).
Included: indicator LED lamp N2191 VD (230 Vac).
White N2102.5 BL 2CLA210250N1101 5
Silver N2102.5 PL 2CLA210250N1301 5
Anthracite N2102.5 AN 2CLA210250N1801 5
Champagne N2102.5 CV 2CLA210250N1901 5
Switch 1-gang, 2-way, SP - 2 M
Rated voltage: 110 - 250 Vac.
Rated current: 16AX.
Screwless terminals.
4 wires (Neutral conductor required).
Included: indicator LED lamp N2191 VD (230 Vac).
White N2202.5 BL 2CLA220250N1101 5
Silver N2202.5 PL 2CLA220250N1301 5
Anthracite N2202.5 AN 2CLA220250N1801 5
Champagne N2202.5 CV 2CLA220250N1901 5
