11/428 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Zenit
Push buttons Rocker covers with symbol

Color Article-No. Order-No. Pack/Qty Color Article-No. Order-No. Pack/Qty

Push-button, SP without symbol - 1M Rocker cover with symbol housing - 1M
Rated voltage: 110 - 250 Vac. Spare rocker cover with housing for N2004.X symbols.
Rated current: 16A. Suitable for N2101.X, N2102.X, N2110 and N2104.X inserts.
Screwless terminals.
1-gang, 1-way - Normally Opened (NO) contact.
Optional: locator LED lamp N2191 BL (127 Vac) or N2191
VD (230 Vac).

White N2104.7 BL 2CLA210470N1101 20 White N2101.9 BL 2CLA210190N1101 10
Silver N2104.7 PL 2CLA210470N1301 20 Silver N2101.9 PL 2CLA210190N1301 10
Anthracite N2104.7 AN 2CLA210470N1801 20 Anthracite N2101.9 AN 2CLA210190N1801 10
Champagne N2104.7 CV 2CLA210470N1901 20 Champagne N2101.9 CV 2CLA210190N1901 10
Push-button, SP without symbol - 2M Rocker cover with symbol housing - 2M
Rated voltage: 110 - 250 Vac. Spare rocker cover with housing for N2004.X symbols.
Rated current: 16A. Suitable for N2201.X, N2202.X, N2210 and N2204.X
Screwless terminals. inserts.
1-gang, 1-way - Normally Opened (NO) contact.
Optional: locator LED lamp N2191.1 BL (127 Vac) or N2191
VD (230 Vac).

White N2204.7 BL 2CLA220470N1101 10 White N2201.9 BL 2CLA220190N1101 10
Silver N2204.7 PL 2CLA220470N1301 10 Silver N2201.9 PL 2CLA220190N1301 10
Anthracite N2204.7 AN 2CLA220470N1801 10 Anthracite N2201.9 AN 2CLA220190N1801 10
11
Champagne N2204.7 CV 2CLA220470N1901 10 Champagne N2201.9 CV 2CLA220190N1901 10
Push-button, SP with label holder - 2M Rocker cover with symbol housing - 3M
Rated voltage: 110 - 250 Vac. Spare rocker cover with housing for N2004.X symbols.
Rated current: 16A. Suitable for N2301, N2302, N2310 and N2304inserts.
Screwless terminals.
1-gang, 1-way - Normally Opened (NO) contact.
Optional: locator LED lamp N2191.1 BL (127 Vac) or N2191
VD (230 Vac).
White N2301.9 BL 2CLA230190N1101 5
White N2204.8 BL 2CLA220480N1101 10 Silver N2301.9 PL 2CLA230190N1301 5
Silver N2204.8 PL 2CLA220480N1301 10
Anthracite N2301.9 AN 2CLA230190N1801 5
Anthracite N2204.8 AN 2CLA220480N1801 10 Champagne N2301.9 CV 2CLA230190N1901 5
Champagne N2204.8 CV 2CLA220480N1901 10
Symbols
Symbols for N2X01.9 rocker covers.

Key symbol N2004.1 2CLA200410N1101 10
Fan symbol N2004.2 2CLA200420N1101 10
WC symbol N2004.3 2CLA200430N1101 10
Room service symbol N2004.4 2CLA200440N1101 10
Nurse symbol N2004.5 2CLA200450N1101 10
Dot symbol N2004.6 2CLA200460N1101 10
