11/596 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Millenium - Grid system for combination (AMD)
Triple rocker switch Socket outlet

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Push button 3-gang, 2-way, triple rocker 10AX Universal socket outlet
Rated voltage: 250Vac Rated voltage/current: 230Vac/13A, 127Vac/15A
Rated power: 10AX Total Child protection
Combination with frames
AMD5144-XX & AMD5244-XX

Stainless Steel AMD43053-ST 2CLA630400N1101 10 Anthracite AMD39144-AN 2CLA623900N1801 1
Silk Black AMD43053-SB 2CLA630400N1501 10 White AMD39144-WP 2CLA623900N2001 1
Antique Gold AMD43053-AG 2CLA630400N1601 10
Matt Gold AMD43053-MG 2CLA630400N1701 10 USB charger
White Glass AMD43053-WG 2CLA630400N3001 5
USB charger 2A, 1-gang - 1M
Black Glass AMD43053-BG 2CLA630400N3101 5 Input voltage: 110-230V AC ± 10%; 50/60 Hz
Input current: <0.2A AC at maximum load
Triple rocker & KNX sensor frames Consumption in standby:
<10 mW at 230 VAC, without load
Nominal output voltage: 5 VDC +5/-5%
Triple rocker switch/KNX sensors frame 1-gang Output current per plug: 2000mA at 5 V DC
Includes metal mounting frame Operating temperature: 0ºC to 45ºC
Dimensions 86x86 mm.
Energy efficiency: > 79%
Overload protection and auto-restart
Combination with frames:
AMD5144-XX & AMD5244-XX
Stainless Steel AMD5153-ST 2CLA637100N1101 10
Anthracite AMD85222-AN 2CLA618520N1801 1
Silk Black AMD5153-SB 2CLA637100N1501 10
11
White AMD85222-WP 2CLA618520N2001 1
Antique Gold AMD5153-AG 2CLA637100N1601 10
Matt Gold AMD5153-MG 2CLA637100N1701 10
USB charger 1.500mA, 2-gang - 2M
White Glass AMD5153-WG 2CLA637100N3001 10 "Input voltage: 100 - 240 Vac ±10%; 50/60 Hz.
Black Glass AMD5153-BG 2CLA637100N3101 10 Input current: 0,20 A (with maximum load).
Output voltage: 5 Vdc ±5%.
Output current: 1.500 mA (total for both gangs).
Triple rocker switch/KNX sensors frame 2-gang Power consuption in stand-by: <= 0,3W@230Vac.
Includes metal mounting frame Energy efficiency: >= 71%.
Dimensions 86x147 mm. Operating temparature: 0ºC to 35ºC.
Combination with frames:
AMD5144-XX & AMD5244-XX
Anthracite AMD85144-AN 2CLA628500N1801 1
Stainless Steel AMD5253-ST 2CLA667200N1101 10
White AMD85144-WP 2CLA628500N2001 1
Silk Black AMD5253-SB 2CLA667200N1501 10
Antique Gold AMD5253-AG 2CLA667200N1601 10
Matt Gold AMD5253-MG 2CLA667200N1701 10
White Glass AMD5253-WG 2CLA667200N3001 5
Black Glass AMD5253-BG 2CLA667200N3101 5
