Millenium - Grid system for combination (AMD)
ABB free@home®

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

For dimming 230 V~ loads. For controlling the room temperature with
With integrated universal dimming actuator for thermostat fuctions. Control of conventional
controlling different lamps. actuators or analog actuator (constant regulation)
The dimming function is available also without prior with the HA-M-0.6.1 and HA-M-0.12.1 actuators.
programming (pre-configured). With NOMINAL temperature indication. Only
Only to be used in combination with ABB-free@home® to be used in combination with ABB-free@home®
2/4-Fold sensor cover plate. room temperature controller cover plate.
44 mm. × 44 mm. × 45 mm. 44 mm. × 44 mm. × 45 mm.
Outputs: 1× dimming channel. Visualization: LCD status mode indicator.
Suitable for: 230 V incandescent lamps and low-voltage Protection class of device: IP 20.
halogen lamps Mounting depth: 14 mm.
with conventional transformers or electronic
transformers. RTC-F-1.PB 2CKA006220A0276 1
Rated power: 10 – 180 W / VA.
Suitable for: LEDi and energy-saving bulbs; typical. Room temperature controller cover plate.
Rated power: 2 – 80 W / VA Cover plate ABB-free@home® for RTC-F-1.PB
Protection class of device: IP 20.
Mounting depth: 32 mm.
SDA-F-2.1.PB.1 2CKA006220A0236 1

Anthracite CP-RTC-AMAN 2CLA624060N1801 5
For controlling blind and awning motors.
With integrated blind actuator. White CP-RTC-AMWP 2CLA624060N2001 5
Blind function is available also without prior
programming (pre-configured).
Only to be used in combination with ABB-free@home® Watchdog sensor 180° with lens for the detection 11
2/4-Fold sensor cover plate. of animals. For the automatic switching of the
44 mm. × 44 mm. × 45 mm. ABB-free@home® actuators.
Outputs: 1× Change-over contacts/ normally open Only to be used in combination with ABB-free@home®
contact, potentialbound. Rated power: 920 VA. Rated Watchdog 180° flush mounted cover plate.
44 mm. × 44 mm. × 45 mm.
current: 4 A. Detection range: 6m front, 3m lateral.
Suitable for: Operating mode blind. Angle: 180°.
Protection class of device: IP 20. Brightness range: 1-500 Lux.
Mounting depth: 32 mm.
Protection class of device: IP 20.
SBA-F-2.1.PB.1 2CKA006220A0238 1 Mounting depth: 9 mm.
MSA-F-1.1.PB.1 2CKA006220A0231 1
For sending switching, dimming and blind commands
to an ABB-free@home® actuator. Watchdog sensor 180 cover plate.
Only to be used in combination with ABB-free@home® Cover plate ABB-free@home® for Watchdog sensor
2/4-Fold sensor cover plate. MSA-F-1.1.PB.1.
44 mm. × 44 mm. × 45 mm. Combination with frames AMD5144-XX & AMD5244-XX.
Control: Push buttons up/down.
LEDS: Used as orientation light or as switching status.
Protection class of device: IP 20.
Mounting depth: 9 mm. Anthracite CP-MD-AMAN 2CLA624160N1801 5
SU-F-2.0.PB.1 2CKA006220A0223 1 White CP-MD-AMWP 2CLA624160N2001 5

2/4-Fold sensor cover plate Light symbol button ABB-free@home®
Cover plate ABB-free@home® 2/4-Fold sensor for Blind symbol button ABB-free@home®
the SSA-F-2.1.PB.1, SSA-F-2.2.PB.1, SDA-F-2.1.PB.1, Scene symbol button ABB-free@home®
SBA-F-2.1PB.1 and SU-F-2.0.PB.1sensors. Dimmer symbol button ABB-free@home®
Combination with frames AMD5144-XX & AMD5244-XX

Anthracite SR-4-AMAN 2CLA622640N1801 5 Light
symbol F@H SBL-AMAN 2CLA602610N1801 20
White SR-4-AMWP 2CLA622640N2001 5
Blind
symbol F@H SBB-AMAN 2CLA602620N1801 20
Scene
symbol F@H SBS-AMAN 2CLA602630N1801 20
Dimmer
symbol F@H SBD-AMAN 2CLA602640N1801 20
