ABB i-bus® KNX
Movement and Presence Detection

Infrared Hand Transmitter for Watchdog Sensor
For Busch-Watchdog 220 MasterLINE KNX premium. The functions can be freely assigned.
With coded transmission signal. Power supply: lithium button cell battery. Type CR202 (in-
cluded in delivery). Battery life: typically 2 years. Rated voltage: 3 V, Protection class (Device):
IP 40, Temperature range (Device): 0 °C – 45 °C, Dimensions: (L x W x D): 86 mm x 40 mm x
7 mm.

6179-500 Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code € kg pc.
grey / anthracite – 6179-500 2CKA006132A0320 0.58 1

Ceiling/corner adapter
For Busch-Watchdog 220 MasterLINE, Busch-Watchdog 220 MasterLINE select,
Busch-Watchdog 220 MasterLINE premium, Busch-Watchdog 280 MasterLINE, Busch-Watch-
dog 220 MasterLINE KNX, Busch-Watchdog 220 MasterLINE KNX premium. For detection on
6868-201-500 two sides of the house, in combination with Busch-Watchdog 280. For ceiling mounting
of the Busch-Watchdog.
To increase the inclination of the Busch-Watchdog 220/280. It is mounted at the corner
of the house, on the wall or under the ceiling. For flush or surface wiring.
Dimensions: (L x W x D): 102 mm x 125 mm x 55 mm. Mounting height: 2.5 m.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code € kg pc.
brown – 6868-201-500 2CKA006800A2565 0.16 1
white 6868-204-500 2CKA006800A2562 0.16 1
silver metallic 6868-208-500 2CKA006800A2563 0.16 1
anthracite 6868-35-500 2CKA006800A2564 0.16 1
