14/158 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ABB i-bus® KNX
User Operation – Design Ranges –
Functional Overview

Busch-priOn® suitable for KNX bus coupler 6120/12-101 or 6120/13
Program
(depending on the specific combination)

6350-825-101 end strip top with 6352-xx-101 end strip bottom with
IR receiver and proximity sensor temperature sensor
KNX function
Switching, rocker switch total – –
Switching, rocker switch left/right – –
Dimming, rocker switch total – –
Dimming, rocker switch left/right – –
Blind, rocker switch total – –
Blind, rocker switch total left/right – –
Short-long operation, rocker switch left/right – –
Value sender, rocker switch total – –
Value sender, rocker switch left/right – –
Value dimming sensor, rocker switch total – –
Red/green LED status illumination (red/green/off) – –
RGB LED function illumination + status illumination – –
Setting the RTC operating mode – –
Value sender, 2 objects, rocker switch left/right – –
Light scene extension unit with light scene memory function – –
Level switch, rocker switch total – –
Level switch, rocker switch total left/right – –
Multiple operation, rocker switch left/right – –
IR remote control channels (up to 13 channels) ■ –
Light scene unit (8 scenes for up to 8 actuators) – –
Light scene unit (10 scenes for up to 10 actuators) – –
Programmable shift key – –
Proximity function ■ –
Room temperature controller only
Temperature reading – ■
RTC settings – –
Illuminated display – –
Fan coil operation for heating and cooling – –

Media box/CD/DVD/radio – –
Short-time timer – –
14
Weekly timer – –
Alarm clock – –
Messages – –
Screen saver – –
Display text/value – –
Device lock – –

Logic function (including light scenes) – –

Busch-Watchdog 4 channels – –

—
 = Function is supported
– = Function is not supported
