ABB i-bus® KNX
User Operation – Design Ranges –
Functional Overview

Program Zenit

6129/98-509 6122/98-509 6124/98-509
3/6 gang with IR
KNX function
Switching, button pair ■ – –
Switching, button upper/lower ■ – –
Dimming, button pair ■ – –
Dimming, button upper/lower ■ – –
Blind, button pair ■ – –
Blind, button upper/lower ■ – –
Short-long operation, button upper/lower ■ – –
Value transmitter, button pair ■ – –
Value transmitter, button upper/lower ■ – –
Value dimming sensor, button pair ■ – –
Value dimming sensor, upper/lower ■ – –
RGB LED function illumination + status illumination ■ – –
Setting the RTC operating mode ■ – –
Value transmitter, 2 objects, button upper/lower ■ – –
Light scene extension unit with light scene memory function ■ – –
Step switch, button pair ■ – –
Step switch, button upper/lower ■ – –
Multiple operation, button upper/lower ■ – –
IR remote control channels (up to 5 channels) ■ – –

Room temperature controller only
Temperature reading – – ■ 14
RTC settings – – ■
Illuminated display – – ■
Fan coil operation for heating and cooling – – ■

10 logic channels (incl. light scene, actuator, sequence actuator,
logic gates, etc.) ■ – ■

Busch-Watchdog 4 channels – ■ –

—
 = Function is supported
– = Function is not supported
