ABB i-bus® KNX
User Operation – Design Ranges – ABB-tacteo

Touch Control Element with Bus Coupler, FM
Freely configurable multifunction control element. The icons and/or texts are configured by
means of a web configuration tool. With integrated KNX bus coupler. With integrated tem-
perature sensor. Push switch function: switching / dimming / blind / sending values /
scenes etc. Support of KNX functions through innovative colour concept (yellow=lighting,
blue=blind, orange=RTC, magenta=scene and white=neutral/no function assigned) or stan-
dard illumination red/green. The bus connection is provided via the enclosed bus terminal.

1-fold
Description Standard Order details Price Dimensions Pack
Design ID 1 piece unit
Type code Order code mm pc.
White F5XVPB7K TB/U1.2.1-CG 2CKA006300A1578 86x115 1
Black F5XVPBZP TB/U1.2.1-CG 2CKA006300A1578 86x115 1
TB/U1.2.1-CG Individual design 1) Go to confi gurator TB/U1.2.1-CG 2CKA006300A1578 86x115 1

2-fold
Description Standard Order details Price Dimensions Pack
Design ID 1 piece unit
Type code Order code mm pc.
White F5XVPB7W TB/U2.7.1-CG 2CKA006300A1580 86x115 1
Black F5XVPBZV TB/U2.7.1-CG 2CKA006300A1580 86x115 1
TB/U2.7.1-CG Individual design 1) Go to confi gurator TB/U2.7.1-CG 2CKA006300A1580 86x115 1

4-fold
Description Standard Order details Price Dimensions Pack
Design ID 1 piece unit
Type code Order code mm pc.
White F5XVPBZ8 TB/U4.7.1-CG 2CKA006300A1581 86x115 1
Black F5XVPBZG TB/U4.7.1-CG 2CKA006300A1581 86x115 1
14
TB/U4.7.1-CG Individual design 1) Go to confi gurator TB/U4.7.1-CG 2CKA006300A1581 86x115 1

6-fold
Description Standard Order details Price Dimensions Pack
Design ID 1 piece unit
Type code Order code mm pc.
White F5XVPBZB TB/U6.7.1-CG 2CKA006300A1582 86x115 1
Black F5XVPBZ5 TB/U6.7.1-CG 2CKA006300A1582 86x115 1
TB/U6.7.1-CG Individual design 1) Go to confi gurator TB/U6.7.1-CG 2CKA006300A1582 86x115 1

The individual design can be selected via the website:
1)
URL: https://tacteo-configurator.eu.mybuildings.abb.com/
