ABB i-bus® KNX
User Operation – Design Ranges – ABB-tacteo

Touch Room Temperature Controller with Bus Coupler, FM
Ordering possible only in connection with the design ID. The icons and/or texts are config-
ured by means of a web configuration tool. Support of KNX functions through innovative co-
lour concept (yellow=lighting, blue=blind, orange=RTC, magenta=scene and white=neutral/
no function assigned) or standard illumination red/green. Control element with room ther-
TR/U.3.1-CG mostat function for controlling TSA/K 230.1, TSA/K 24.1 in connection with KNX-Heating ac-
tuator, commercially available valve drives or analogue valve drives (continuous controllers).
The controller is a constant room temperature controller for ventilator convectors (fan coils)
in 2-pipe and 4-pipe systems and conventional heating or cooling systems. The fan stage can
be switched manually or in automatic mode. Class of temperature controller 1. Contribution
to space heating energy efficiency 1,0 %. With integrated KNX bus coupler.

Description Standard Order details Price Dimensions Pack
Design ID 1 piece unit

Type code Order code mm pc.
White F5XVPB7E TR/U.3.1-CG 2CKA006300A1595 115x86 1
Black F5XVPB7Q TR/U.3.1-CG 2CKA006300A1595 115x86 1
Individual design 1) Go to confi gurator TR/U.3.1-CG 2CKA006300A1595 115x86 1

Busch-Watchdog® 180 Sensor Standard with Bus Coupler, FM
Ordering possible only in connection with the design ID. Movement detector with up to
4 channels. The bus can be connected via enclosed terminal block. With integrated tempera-
ture sensor. With integrated KNX bus coupler.

TBW/U.3.1-CG Description Standard Order details Price Dimensions Pack
Design ID 1 piece unit
Type code Order code mm pc.
White F5XVPB71 TBW/U.3.1-CG 2CKA006300A1596 115x86 1
Black F5XVPB7R TBW/U.3.1-CG 2CKA006300A1596 115x86 1
Individual design 1) Go to confi gurator TBW/U.3.1-CG 2CKA006300A1596 115x86 1 14

Room Outdoor Sensor with Bus Coupler, FM
Ordering possible only in connection with the design ID. The icons and/or texts are config-
ured by means of a web configuration tool. Freely programmable function ”Do not disturb“,
”Bell“ and ”Make up room“. Push switch function: switching / dimming / blind / sending val-
ues / scenes etc. Support of KNX functions through innovative colour concept (yellow=light-
TA/U3.3.1-CG ing, blue=blind, orange=RTC, magenta=scene and white=neutral/no function assigned) or
standard illumination red/green. With integrated KNX bus coupler. The bus connection is
provided via the enclosed bus terminal.

Description Standard Order details Price Dimensions Pack
Design ID 1 piece unit
Type code Order code mm pc.
White F5XVPB7T TA/U3.3.1-CG 2CKA006300A1597 115x86 1
Black F5XVPBZX TA/U3.3.1-CG 2CKA006300A1597 115x86 1
Individual design 1) Go to confi gurator TA/U3.3.1-CG 2CKA006300A1597 115x86 1

The individual design can be selected via the website:
1)
URL: https://tacteo-configurator.eu.mybuildings.abb.com/
