ABB i-bus® KNX
User Operation – Design Ranges – ABB-tacteo

Touch Room Temperature Controller with Bus Coupler, FM
Ordering possible only in connection with the design ID. The icons and/or texts are config-
ured by means of a web configuration tool. Support of KNX functions through innovative co-
lour concept (yellow=lighting, blue=blind, orange=RTC, magenta=scene and white=neutral/
no function assigned) or standard illumination red/green. Control element with room ther-
mostat function for controlling TSA/K 230.1, TSA/K 24.1 in connection with KNX-Heating ac-
tuator, commercially available valve drives or analogue valve drives (continuous controllers).
TR/U.2.1-CG
The controller is a constant room temperature controller for ventilator convectors (fan coils)
in 2-pipe and 4-pipe systems and conventional heating or cooling systems. The fan stage can
be switched manually or in automatic mode. Class of temperature controller 1. Contribution
to space heating energy efficiency 1,0 %. With integrated KNX bus coupler.

Description Standard Order details Price Dimensions Pack
Design ID 1 piece unit

Type code Order code mm pc.
White F5XVPB77 TR/U.2.1-CG 2CKA006300A1583 86x115 1
Black F5XVPB7S TR/U.2.1-CG 2CKA006300A1583 86x115 1
Individual design 1) Go to confi gurator TR/U.2.1-CG 2CKA006300A1583 86x115 1

Busch-Watchdog® 180 Sensor Standard with Bus Coupler, FM
Ordering possible only in connection with the design ID. Movement detector with up to
4 channels. The bus can be connected via enclosed terminal block. With integrated tempera-
ture sensor. With integrated KNX bus coupler.

Description Standard Order details Price Dimensions Pack
Design ID 1 piece unit
TBW/U.2.1-CG
Type code Order code mm pc.
White F5XVPB7X TBW/U.2.1-CG 2CKA006300A1584 86x115 1
Black F5XVPB7V TBW/U.2.1-CG 2CKA006300A1584 86x115 1
Individual design 1) Go to confi gurator TBW/U.2.1-CG 2CKA006300A1584 86x115 1 14

Room Outdoor Sensor with Bus Coupler, FM
Ordering possible only in connection with the design ID. The icons and/or texts are config-
ured by means of a web configuration tool. Freely programmable function ”Do not disturb“,
”Bell“ and ”Make up room“. Push switch function: switching / dimming / blind / sending val-
ues / scenes etc. Support of KNX functions through innovative colour concept (yellow=light-
ing, blue=blind, orange=RTC, magenta=scene and white=neutral/no function assigned) or
standard illumination red/green. With integrated KNX bus coupler. With integrated tempera-
TA/U3.2.1-CG
ture sensor. With integrated proximity function. The bus connection is provided via the en-
closed bus terminal. The device is mounted exclusively via the Italian flush-mounted device
box according to EN60670 (CEI 23-48).

Description Standard Order details Price Dimensions Pack
Design ID 1 piece unit
Type code Order code mm pc.
White F5XVPB75 TA/U3.2.1-CG 2CKA006300A1585 86x115 1
Black F5XVPBZM TA/U3.2.1-CG 2CKA006300A1585 86x115 1
Individual design 1) Go to confi gurator TA/U3.2.1-CG 2CKA006300A1585 86x115 1

The individual design can be selected via the website:
1)
URL: https://tacteo-configurator.eu.mybuildings.abb.com/
